Home > Products > Construction Machinery > HZS60 Wet Concrete Mixing Plant with good quality
HZS60 Wet Concrete Mixing Plant with good quality
- 5 Set / Sets per Month
- Qingdao Shanghai
- T/T Credit Card
- HZS60 Ready Mix Concrete Mixing Production line
- High Quality and Reliable Concrete Batching Plant/ Concrete Batching Mixing Plant for Sale in Africa, Nigeria and Others Country
- HZS60 concrete batch plants/beton batching plant /ready mixied concrete batching plant
- Sincola Full Automatic Concrete Batching Plant Made in China
- HZS30/40 /60/80 concrete batching plant with quality assurance and good service
- concrete mixing plant ,60m3/h concrete batching plant,HZS60 concrete plant
Product Details
Condition: | New | Power Type: | Electric | Place of Origin: | Henan, China |
Brand Name: | Sincola | Model Number: | HZS60 | Power(W): | 120Kw |
Dimension(L*W*H): | 33.8m*14.8m*10.8m | Weight: | 48T | Certification: | ISO9001 |
Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Nude packing, or as per your requirements
Product Description
Model | HZS60 |
Rated Productivity | 60m3/h |
Main Mixer | JS1000 |
Max. Aggregate Diameter | 80mm |
Capacity of Aggregate Bin | 3×8.38m3 |
Aggregate Conveying Mode | Flat Belt Conveyor |
Aggregate Weighing Precision | 3X 3000Kg ±2% |
Cement Weighing Precision | 1500Kg ±1% |
Fly Ash Weighing Precision | 600Kg ±1% |
Water Weighing Precision | 600Kg ±1% |
Additive Weighing Precision | 50Kg ±1% |
General Power | 120Kw |
Total Weight | 48T |
Outline dimension (L*W*H) | 33.8m×14.8m×10.8m |
Discharging Height | 3.8 m |
Powder Silos (for customers choice) | The capacity and number of silos as well as the configuration of silo accessories vary with customers’ demands. |
Screw Conveyors (for customers choice) | Usually, φ273mm screw conveyors are used. |
1. twin shaft concrete Mixer JS1000
2. aggregate batcher PLD1600 with 3 storage bins;
3. cement silo: 100T boltd type (it depends on the customer's choice);
4. screw conveyor: 273mm*8m
5. cement, water, fly ash and additive scales;
6. computer controlled automatic control system.
HZS60 Wet Concrete Mixing Plant is composed of material supply,batching system,mixing,electrial control and steel structure. concrete mixer is ideal concrete equipment for building project, building ground and precast product factory. The main characteristic is:
1.It adopts knockdown structure and blocking. It is combine mode.
2. Wet Concrete Mixing Plant adopts JS1000 concrete mixer, it has good mixing quality and high efficiency.
3. Wet Concrete Mixing Plant is measuring nicety and high produce efficiency.
4.The forced water supply system spray equably and has washing function for the mixing system.
5. Wet Concrete Mixing Plant adopts the ectctrial weigher to measure all the aggregate,cement,water,liquid additive.
6.The electrical system adopts import parts and has credibility performance.
Any questions, Please feel free to ask me.
Company Profile
Zhengzhou Sincola Machinery Co., Ltd. is a high-technology, modern enterprise professionally engaged in the R&D and manufacturing of full automatic dry mortar plant and semi automatic dry mortar production line 1-5tph dry mortar plant and shotcrete machine plaster machine and mortar pump,wall rendering machine,concrete pump etc.
