Zhengchi 20kva diesel generator on Promotion
| MODEL | ZCDL-Q22 | |||||||
| Standby Power(50Hz) | 22KVA | |||||||
| Prime Power(50Hz) | 20KVA | |||||||
| ENGINE DATA | ||||||||
| Manufacturer and Model: | Quanchai / QC490D | |||||||
| Air Intake System: | Natural | |||||||
| Cool System: | Water-cooled | |||||||
| Fuel System: | Direct Injection | |||||||
| Cylinder Arrangement: | 4 in line | |||||||
| Bore and Stroke: | 90×105(mm) | |||||||
| Rated RPM: | 1500rpm | |||||||
| Rated Power: | 22kw | |||||||
| Discharge Fan Diameter: | φ410 mm | |||||||
| Displacement: | 2.672L | |||||||
| Governor Type: | Mechanical | |||||||
| 100%(Prime Power) Load Consumption: | ≤243 g/kw.h | |||||||
| Engine Radiator: | Radiator cooled, fans driven by belt | |||||||
| Start Type: | 24V Direct Current Start, Including alternator & battery | |||||||
| Filter System: | Dry type air filter, fuel filter, oil filter | |||||||
| ALTERNATOR DATA | ||||||||
| Rated Power: | 20 kva | |||||||
| Power Factor: | 0.8 | |||||||
| Altitude: | ≤1000m | |||||||
| Insulation Class, Temperature Rise: | H/H | |||||||
| Telephone Influence Factor (TIF): | <50 | |||||||
| THF: | <2% | |||||||
| GENERATING SET DATA | ||||||||
| Voltage Regulation, Stead State: | ≤±1% | |||||||
| Sudden VoltS Warp(100%): | ≤+20% | |||||||
| Sudden Voltage Warp(Sudden Increase): | ≤-15% | |||||||
| Voltage Stable Time: | ≤4S | |||||||
| Frequency Regulation, Stead State: | ≤5% Adjustable | |||||||
| Frequency Waving: | ≤±0.5% | |||||||
| Sudden Frequency Warp(100%): | ≤-7% ~ +10% | |||||||
| Attached Accessories: | Starting batteries and connective wire, exhaust pipe, muffler, damper, MCCB breaker |
|||||||
| Standards: | CE, ISO9001, ISO14001 | |||||||
| Silent Type Size: | 1830(mm)*900(mm)*1220(mm) | |||||||
| Silent Type Weight: | 620kg | |||||||
| Control Panel: | Key manual control panel | |||||||
20kva diesel generator Packaging: nude or plywood package
Shipping: 15 days after deposit
(1) Global service after sale (spare part, maintenance, local service)
(2) 20kva diesel generator Warranty Time: 1 year or 1000 running hours, which occurs the first
Yangzhou Zhengchi Power Equipment Co.,LTD., located in Yangzhou City, Jiangsu Province, which is the central part of manufacturing 20kva diesel generator industrial zone in Southeast China. ZC Power manufactures OEM generator powered by Cummins, Perkins, Deutz, Volvo, MTU, Doosan engines and Stamford, Leroy Somer, Mecc Alte alternators. ZC Power Genset ranges from 7KW to 2400KW, 50Hz or 60Hz frequency, with open type, silent type, trailer type and containerized type, etc.
Besides manufacturing OEM 20kva diesel generator, we also supply various power products to meet customer one-stop solutions, such as transformers, power cables, control panel, generator spare parts, field service, etc.
(1) Your company is factory or Trade Company?
Answer: We are professional 20kva diesel generator manufacturing factory.
(2) Your diesel generator power range?
Answer: Now we mainly produce 7KW to 2400KW 20kva diesel generator.
(3) Which brand Electrical Generator you produce?
Answer: Now we produce USA brand Electrical Generator, Sweden Volvo Generator, Korea Doosan diesel generator, German Deutz Electrical Generator, and China local brands' generator.
(4) Where is your main market?
Answer: We mainly export 20kva diesel generator to Africa, Middle East, Asia, and South Korea...
