Specifications
1.High productivity;2.Low heat consumption;
3.Stable clinker quality;
4.High ecomomic efficiency.
2014 Best Sell Rotary Kiln for activated carbon
Rotary kiln is the key equipment in cement industry for calcinating clinker. It is also used in varies industries, such as metallurgy, Chemical, building, rehractory material, environmental production, etc. The kiln is composed of the cylindrical shell, roller supporting device with thrust roller, driving gear unit movable kiln hood, sealing device at kiln inlet, coal dust pipe device etc.
With a certain slope to the level, the whole kiln body is supporting rollers and fitted with thrust rollers to contral up and down movement of the kiln body. Besides main driving unit for driving system, if is also fitted with auxiliary driving unit so as to ensure the kiln could be kiln head sealing adopts housing type sealing and kiln rear uses axial contact sealing unit so that reliability of sealing be ebsures.
Types of rotary kiln:
- Cement kiln;
- Metallurgy chemical kiln;
- Active lime kiln;
- Porcelain kiln according;
- Building material kiln;
- Calcined petroleum coke rotary kiln.
Application of rotary Kiln:
- Rotary kiln is the Thermal Equipment, heating materials, in cement industry for calcining clinker.
- It is also used in various industries, such as cement, nonferrous metallurgy, ferrous metallurgy, chemistry, building, refractory material, environmental protection, etc.
Types of rotary kiln:
| Technical paramenters of ratary kiln | |||||||||||
| Specifications | Technical parameters | main reducer | main motor | Catch wheel form | The number of support | Weight(t) | |||||
| Roller speed (r/min) | slope(%) | production(t/h) | model no | Speed ratio | model no | power (kw) | speed (r/min) | ||||
| Φ1.9/1.6* 36m | 0.53-1.59 | 4 | 2.5-3 | JZQ750-1 | 48.58 | JZT-72-4 | 30 | 1200/400 | Mechanical | 3 | 53 |
| Φ2.1/1.8* 36m | 0.5-1.51 | 4 | 4 | UT2-110 | 163.36 | JZS-81 | 30/10 | 1410/470 | Mechanical | 3 | 75 |
| Φ1.2*25m | 0.5-1.6 | 3 | PM650 | 40.17 | JZTY71-4 | 22 | 1200/120 | Mechanical | 3 | 34 | |
| Φ1.6*32m | 0.158-0.258 | 3 | PM750 | 48.57 | JZJY61-4 | 15 | 1200/120 | Mechanical | 3 | 46.82 | |
| Φ1.8*45m | 0.66-1.98 | 4 | 3.5 | UT2-110 | 163.36 | JZS-81 | 30/10 | 1410/470 | Mechanical | 3 | 80 |
| Φ2.2*50m | 0.125-1.25 | 3.5 | 4 | ZS145-11 | 157 | YCT280-4A | 30 | 1320/132 | Mechanical | 3 | 130.71 |
| Φ2.5*50m | 0.516-1.549 | 3.5 | 5.5 | ZS165-7 | 99.96 | YCT355-4A | 55 | 1320/440 | Mechanical | 3 | 167.5 |
| Φ3*48m | 0.3309-3.309 | 3.5 | 35 | ZL130-14 | 32.11 | ZSN4-250-21B | 90 | 1000/100 | Mechanical | 3 | 237 |
| Φ3.2*50m | 0.398-3.975 | 3.5 | 50 | ZL130-16 | 40.85 | ZSN4-280-11B | 190 | 1500/150 | Mechanical | 3 | 263 |
| Φ3.3*52m | 0.391-3.91 | 3.5 | 50 | ZSY500-28 | 27.707 | ZSN4-315-082 | 190 | 1000/100 | Mechanical | 3 | 280.8 |
| Φ4*60m | 0.396-3.96 | 3.5 | 104 | ZSY630-35.5 | 34.601 | ZSN4-355-092 | 315 | 1000/100 | Mechanical | 3 | 487.5 |
| Φ4.2*60m | 0.4165-4.165 | 3.5 | 116 | ZSY710-35.5 | 35.526 | ZSN4-355-12 | 420 | 1000/100 | Mechanical | 3 | 576.1 |
| Φ4.3*62m | 0.398-3.98 | 3.5 | 125 | ZSY710-35.5 | 35.714 | ZSN4-355-12 | 420 | 1000/100 | Mechanical | 3 | 5985 |
| Φ4.8*74m | 0.35-4 | 4 | 208 | JH710C-SW305-40 | 42.226 | ZSN4-400-092 | 630 | 1500/130 | Mechanical | 3 | 841 |
Packaging Detail: |
The package of rotary kiln is Standard container, spare parts will be packed in wooden cases |
Delivery Detail: |
Rotary kiln is delivered 30 days after receiving payment |
(Shandong. China)Zhangqiu Long Teng Cement Machinery Making Co., Ltd. is Zhangqiu Building Material Equipment Factory established in 1970, and the factory is formally restructured and registered as Zhangqiu Long Teng Cement Machinery Making Co., Ltd in 2002. The company has become one of the new domestic cement equipment and mining equipment manufacturing enterprises after constructing and developing for 40 years.
How about the quality of your rotary kiln?
- Our rotary kiln manufactured strictly according to national and international standard.
- We take a test on every rotary kiln before delivery.
How about price of rotary kiln?
- We can give the lowest price of the rotary kiln than market one.
- We do quotation of rotary kiln as soon as possible for any custome.
- Discount of rotary kiln can be given according to quantity.
How about the after-sale service of your company?
- Our engineer is aviliable to installation rotary kiln overseas.
- The guarantee period of our rotary kiln is one year.
