Bare conductors ACSR Linnet 336.4MCM

Specifications

Bare conductors ACSR Linnet 336.4MCM
Professional supplier
Reliable quality,good price
Strong capacity,fast delivery
Grease

Bare Conductors ACSR Linnet 336.4MCM



Specification                             ACSR                                    ACSR/AW

Code Name:                              Linnet                                    Linnet

Standard:                                  ASTMB232.                           ASTM B549-88

Stranding/wire Dia.                   Al: 26/2.89 mm.                       Al: 26/2.89 mm.

                                                 St: 7/2.25 mm.                         ACS:7/2.25 mm.

Approx.Overall Dia.:                 18.31 mm.                                18.31 mm.

Linear Mass:                             689 kg/km.                               656 kg/km.

Nominal Breaking Load:            62.71 kN.                                 59.95 kN.

Max.D.C.Resistance at 20°c:    0.1699 ohm/km.                        0.161 ohm/km.

*ACSR/AW:Aluminum conductors aluminum clad steel reinforced



1.Application

ACSR or ACSR cable or ACSR conductor used for Overhead electrical distribution and transmission lines for distributing power cable. ACSR offers optimal strength for line design.

Variable steel core stranding enables desired strength to be achieved without sacrificing ampacity.



2.Construction

Aluminum alloy 1350-H-19 wires, concentrically stranded about a steel core.Core wire for ACSR is available with class A, B, or C galvanizing; aluminum coated (AZ); Or aluminum-clad (AW). Additional corrosion protection is available through the application of grease to the corer or infusion of the complete cable with grease.



3.Specifications

B-230 Aluminum Wire, 1350-H19 for Electrical Purposes.

B-231 Aluminum Conductors, Concentric-Lay-Stranded.

B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR).

B-341 Aluminum-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AZ).

B-498 Zinc-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AZ).

B-500 Zinc Coated and Aluminum Coated Stranded Steel Core for Aluminum Conductors.



4.Code Name of ASTMB232
