Overhead Types od Electric Conductor Hard Drawn Aluminum Conductor HDA 50mm AAC ANT

Name: Overhead Types od Electric Conductor Hard Drawn Aluminum Conductor HDA 50mm AAC ANT
Brand: Jinshui
SKU: 114420591
Availability: InStock

Overhead Types od Electric Conductor Hard Drawn Aluminum Conductor HDA 50mm AAC ANT thumbnail-1

Overhead Types od Electric Conductor Hard Drawn Aluminum Conductor HDA 50mm AAC ANT photo-1

US$ 0.5 - 15 MOQ: 3 Kilometers

Key Specifications

Get Latest Price

Place of Origin:

Henan, China

Brand Name:

Jinshui

Model Number:

AAC ANT

Contact Supplier Request Quote Chat Now

Henan Jinshui Cable Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Henan, China

Brand Name Jinshui

Model Number AAC ANT

Insulation Material Other, bare

Type High Voltage

Application Overhead

Conductor Material Aluminum

Jacket Other, Bare

Hard Drawn Aluminum Conductor AAC HDA 50mm2 ANT

Standard of AAC Ant conductor

IEC61089, BS215-1, ASTM B231, DIN48201

Construction of AAC Ant Conductor

AAC conductor is composed by bare concentric-lay-stranded aluminum wires with a straight round central aluminum wire surrounded by one or more layers of helically layed aluminum wires

Features and Benefits of AAC Ant Conductor

AAC Conductor is widely used in power transmission lines with various voltage levels, since they thave such good characteristics as simple structure, convenient installation and maintenance, low cost for the line, large transmission capacity and are also suitable for laying across rivers and valleys where special geographical features exist.

Application

AAC conductor is used in overhead electric power transmission and distribution lines with various grade voltage

Specification

BS 215-1 AAC

Code Name	Nominal Area	No./Nominal Diameter of Wires	Approximate Overall Diamter	Total Area	Approximate Weight	Nominal Breaking Load	Nominal DC Resistance at 20℃	Current Rating (*)
Code Name	mm2	No./mm	mm	mm2	kg/km	KN	ohm/km	A
Midge	22	7/2.06	6.18	23.33	64	3.99	1.22700	106
Ant	50	7/3.10	9.30	52.83	145	8.28	0.54190	175
Fly	60	7/3.40	10.20	63.55	174	9.90	0.45050	196
Wasp	100	7/4.39	13.17	106.00	290	16.00	0.27020	268
Hornet	150	19/3.25	16.25	157.60	434	25.70	0.18250	342
Chafer	200	19/3.78	18.90	213.20	587	32.40	0.13490	412
Cockroach	250	19/4.22	21.10	265.70	731	40.40	0.10830	471
Butterfly	300	19/4.65	23.25	322.70	888	48.75	0.08916	530
Centipede	400	37/3.78	26.46	415.20	1145	63.10	0.06944	616
