Home > Packaging & Printing > Printing Machinery > Rotogravure Printing Machine > Computer Color Register Rotogravure Printing Machine /the Speed 150m/min
Computer Color Register Rotogravure Printing Machine /the Speed 150m/min
US$ 86,500 - 135,200
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
FangBang
Payment & Shipping
Payment Methods:
Port of Shipment:
NingBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Zhejiang, China
Brand Name
FangBang
Model Number
AZJ-B Series
Usage
Paper Printer, Other, Paper Printer, Plastic printer
Automatic Grade
Semi-Automatic
Voltage
220V/380V
Gross Power
182KW
Dimensions(L*W*H)
14500*3900*3400
Weight
24000KG
Certification
CE,ISO9001
Warranty
One year
After-sales Service Provided
Engineers available to service machinery overseas
To be the Best Printing&Packaging Manufacture in China
Company introduction:
- 14 years experience in packing industrial
- Appliance is strictly in accordance with CE standard
- Assembly&parts are processed by CNC lathe
- Good after-sale service
- Prompt reply within 24 hours
- Professional&enthusiastic sales team
FangBang Development History:
- August ,1999 ---Ruian.jianshe Packing Equipment Co.,Ltd ,Was established
- April ,2002 ---Shanghai Fangbang industry Co.,Ltd Wad established
- October, 2003 ---Main products passed the inspection of Zhejiang Province Light Industry Machine Quality Supervision and Inspection Center,past the Province Level Authentication an listed by Govenment Authorities as the new products
- August .2005 ---Jiangsu Fangbang Machinery Co.,Ltd Was established
- October .2005 ---Passed ISO9001:2000 Authentication
- May,2006 ---Zhejiang Fangbang Machiery Co.,Ltd .Was established
- Augus,2006 --- Passed CE Authentication
- July ,2010 --- The Famous Product of Ruian City
- September ,2010 -- The Famous Brand of Ruian City
- August,2011 --- National High&New Technology Enterprise
Computer color register rotogravure printing machine
Computer color register rotogravure printing machine is suitable for multi-color once-through continuous printing for such roll film materials with excellent printing performance as BOPP,PET.PVC,PE ,Aluminum foil and paper ,etc
------ Skype: zhezhoutiankong -----
| Type | AZJ-8850B | AZJ-81050B | AZJ-81250B |
| Max.Width of Web | 850mm | 1050mm | 1250mm |
| Max.Printing Speed | 130-150m/min | 130-150m/min | 130-150m/min |
| Max.Diameter of Unwind/Rewind | 600mm | 600mm | 600mm |
| Internal Diameter of RollCore | 76mm | 76mm | 76mm |
| Diameter of Printing Cylinder | 105-380mm | 105-380mm | 105-380mm |
| Accuracy of Registration | ± 0.1mm | ± 0.1mm | ± 0.1mm |
| Tension Control Range | 3-25kg/Full Width | 3-25kg/Full Width | 3-25kg/Full Width |
| Heating Power of Oven | 108kw | 135kw | 162kw |
| Total Power | 109kw | 136kw | 160.5kw |
| Weight of Machine | 18000kg | 20000kg | 22000kg |
| Overall Dimension | L13300*W3200*H2500mm | L13300*W3400*H2500mm | L13300*W3600*H2500mm |
The Certificate :
Characteristics:
- Every control module of the automatic color register system is equipped with microprocessor and can correct the deviation of color register quickly and accurately
- Main motor equipped with frequency converter for speed regulation
- Unwinding tension adopts automatic tension controller and magnetic powder brake
- Rewinding adopts torque motor,double-station automatic turret
- Closed oven and independent heating hot air blosing system ,automatic constant temperature system
- Pneumatic impressing system and pneumatic doctor blade system
- Diaphragm-type pneumatic ink auto circulating system
- Inflatable air shaft for unwinding/rewinding material loading
- Printing linear speed and meter counting display
- Shaft less printing cylinder loading device .Printing cylinder is fixed by shaft-less air chuck.
- Max.Printing Speed :150m/min
- Max.Diamter of Unwind/Rewind: 600mm
~~If you have any interests.Pls contact us freely .
The most competitive price fo you !
Workshop:
Spart parts Room :
