Home > Packaging & Printing > Packing Machinery > Laminating Machine > Dry-type Laminating Machine Price
Dry-type Laminating Machine Price
US$ 39,600 - 45,600
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Other, Food, Machinery & Hardware
Packaging Type:
Bags, Film, Foil
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Dry-type Film Laminating Machine ForBOPP.PET Quality ChoiceUS$ 39,600 - 45,600MOQ: 1 Set -
Automatic Laminating Machine GF-D SeriesUS$ 110,700 - 118,100MOQ: 1 Set
-
GF-D Series High Speed Laminating MachineUS$ 110,700 - 118,100MOQ: 1 Set
-
2015 New GF-D High Speed Laminating Machine for BOPP,PET,Nylon ,CPP,CPE.Aluminum Foil and Paper.etcUS$ 110,700 - 118,100MOQ: 1 Set
-
High Speed Laminating Machine 180m/minUS$ 110,700 - 118,100MOQ: 1 Set
Condition
New
Application
Food, Other, Food, Machinery & Hardware
Packaging Type
Bags, Film, Foil
Packaging Material
Plastic
Automatic Grade
Semi-Automatic
Driven Type
Pneumatic
Voltage
380/220V
Power
92KW
Place of Origin
Zhejiang, China
Brand Name
FB
Model Number
GF-C Series
Dimension(L*W*H)
11000*2700*3100mm
Weight
10000kg
Certification
CE.ISO9001:2008
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
GF-C Series High-speed Dry-type Laminating MachineThe max.speed :130m/min
Double arm and double station loading material
To be the Best Printing&Packaging Manufacture in China
Company introduction:
- 14 years experience in packing industrial
- Appliance is strictly in accordance with CE standard
- Assembly&parts are processed by CNC lathe
- Good after-sale service
- Prompt reply within 24 hours
- Professional&enthusiastic sales team
FangBang Development History:
- August ,1999 ---Ruian.jianshe Packing Equipment Co.,Ltd ,Was established
- April ,2002 ---Shanghai Fangbang industry Co.,Ltd Wad established
- October, 2003 ---Main products passed the inspection of Zhejiang Province Light Industry Machine Quality Supervision and Inspection Center,past the Province Level Authentication an listed by Govenment Authorities as the new products
- August .2005 ---Jiangsu Fangbang Machinery Co.,Ltd Was established
- October .2005 ---Passed ISO9001:2000 Authentication
- May,2006 ---Zhejiang Fangbang Machiery Co.,Ltd .Was established
- Augus,2006 --- Passed CE Authentication
- July ,2010 --- The Famous Product of Ruian City
- September ,2010 -- The Famous Brand of Ruian City
- August,2011 --- National High&New Technology Enterprise
Dry-type laminating machine price
Dry-type laminating film from ruian is suitable for multi-color once-through continuous printing for such roll film materials with excellent printing performance as BOPP,PET.PVC,PE ,Aluminum foil and paper ,etc
------ Skype: zhezhoutiankong -----
| Type | GF-650C | GF-850C | GF-1050C |
| Max.Laminati ng Width | 600mm | 800mm | 1000mm |
| Max.Web Width | 650mm | 850mm | 1050mm |
| Max.Laminati ng Speed | 130m/min | 130m/min | 130m/min |
| Max.Diameter of Roll Core | 600mm | 600mm | 600mm |
| Internal Diameter of Roll Core | 76mm | 76mm | 76mm |
| Length of Drying Channel | 9000mm | 9000mm | 9000mm |
| Power for Drying Channel | 54kw | 63kw | 72kw |
| Total Power | 74kw | 83kw | 92kw |
| Weight of Machine | 8000kg | 9000kg | 10000kg |
| Overall Dimension | 11000*2300*3100mm | 11000*2500*3100mm | 11000*2700*3100mm |
Characteristics:
- Coating and laminating of main machine are of double-shaft synchronous frequency conversion and feedback control
- Thickness of glue coating can be chosen by mesh of anilox roller and doctor blade
- Auto tension controller for three section constandt tension control
- Turret type unwinding station.pre-tension control for non-stop shaft exchange
- Unwinding station equipped with EPC system
- Turrent type rewinding station ,pre-tension control for non-stop shaft exchange
- Movable doctor blade with pneumatic back pressure
- Three independent constant temperature section drying system with heating tube and strong air fans for air in feeding and exhaust to ensure the full dryness of web
- Pneumatic lifting drying channel and operating platform for web passing .active synchronous running leading roller inside drying channel
- Pre-heating before laminating ,water colling roller for laminated web
- Inflatable air shaft for web loading /unloading
- Three rollers nip laminating method,laminating pressure more even to ensure higher peel strength
The Certificate :
