Specifications
KO-Face100 visual recognition time attendance1.300 users, 200, 000 capacity;
2.TCP/IP(optional)
3.2.8"TFT
KO-Face100 applications of face recognition system
1. Patented and advanced FIRS facial image +V4.0 recognition algorithm to ensure operation speed and user’s safe.
2. High Recognition Accuracy and Speed: Recognition Rate >99 %, False Acceptance Rate (FAR) <0.1%; Recognition Speed <1s
3. Excellent light adaptability, Excellent light adaptability. And Intelligent self-learning function: No influence of glasses, hair style, age, and other small changes of face.
4. 2.8 inch color Touch screen, 320*240 Resolution; Support TCP/IP and USB communication interface.
5. Economical model suits for SMEs; 1: N (100 users) for G1 model, 6. Adopt FIRS patent non-visible auxiliary light, harmless for users.
7. 24 hours time attendance; easy to operate, humanized interface.
8. Support embedded Web server and FIRS Standard Attendance Management Software.
9. Out of Storage Alarm: When data storage exceed 85%, alarm light triggered, and alarm message shown in LCD
10. Voice reminder for each operation step
11. RTC and Network data synchronization
12. With body sensor function. And supports Anti-disassembly Security alarm
13. SDK available for OEM customers and software developers
Function |
Item |
Face100 |
Face Recognition |
Camera |
Special Dual-Cameras |
Recognition Mode |
Face Only |
|
Maximum User |
300 |
|
Recognition Speed |
<=1s |
|
Recognition Rate |
>=99% |
|
Failure Rate |
<=0.1% |
|
Anger Range |
Horizontal:±20°, Vertical:±20° |
|
Fitting Height |
145-195CM |
|
Recognition Distance |
30-80CM |
|
Card Reader Embedded |
Not Supported |
|
Time Attendance |
Records Supported |
200,000 records |
Attendance Software |
Attendance Management Software |
|
Access Control |
Simple Switch Signal |
Supported |
Data Storage |
USB Data Import/Export |
Supported |
Offline User Profile Edit |
Supported |
|
|
Communication Interface |
I/O(1 Input and 1 Output) |
Switch Signal Only |
RS485 |
Supported |
|
Network |
Support TCP/IP(RJ45 Interface with signal light) |
|
USB |
Supported |
|
Device Management |
Built-in Web server |
Supported |
Admin |
Supported |
|
Out Of Storage Alarm |
When data storage exceed 90%,alarm light triggered, alarm message shown in LCD |
|
Anti-disassembly |
Supported |
|
RTC |
Built-in RTC, Network time synchronization(SNTP) |
|
License Control |
Supported(Built-in security chip) |
|
|
Human-Computer Interaction |
LCD |
TFT, 2.8 Inch LCD 320*240 |
Function Key |
Up to 10 function keys are supported |
|
Touch Screen |
Supported |
|
|
Signal Light |
Red(Alarm/Failed);Green(Running/Successful) |
Operation Prompt |
Supported(Voice, Signal Light) |
|
Voice |
Supported |
|
Buzzer |
Supported |
|
Body Sensor |
Supported |
|
Language |
Chinese(Simplified), Chinese(Traditional), English |
|
Others |
Environment Requirement |
Illumination:0-20000LUX; Water Proof Class 3 Dust Proof Class 6 |
Working Temperature |
20%~80% |
|
Working Humidity |
-20~45°C |
|
Dimension |
133mm(H)*123mm(W)* 120mm(D) |
|
Installation |
Wall Mounting |
