Help CenterSmart Card Door Access Control System W100 With Keypad Waterproof, in Good Performance
Related Products
-
Proximity Card and IC Card Reader KO-10L the Keypad Access Contol ID IC Card SupportUS$ 1 - 100MOQ: 1 Piece -
Proximity Card Reader KO-15L Punch Card Reader Access ContolUS$ 1 - 70MOQ: 1 Piece
-
Proximity Card Reader KO-15L Punch Card SystemUS$ 1 - 70MOQ: 1 Piece
-
KO-18L Access Control Without KeypadUS$ 1 - 70MOQ: 1 Piece
-
IC Card Reader KO-10L the Keyboard Access Contol ID IC Card SupportUS$ 1 - 100MOQ: 1 Piece
Specifications
*Waterproof,whetherproof*Card standard door access control
*Easy to manage by software
*With SDK for further development
Weatherproof Access Controller
1 Perfect disign, keypad with light, plated silver color, popular and fashion.
2. Output with function of protection, waterproof and dampproof, it is fitting to use outside.
3. Strong standalone function device, can be used as WG26 reader alone.
4. Capacity:2000 user’s cards,2000 codes;
5. Access ways : cards ,code, card +code.
6, Low power :static current less than 30mA.
7, Support only keypad ,
8, users can reset private passwords.
9, Search fast less than 0.1s .
10, Muti-function device, can use WG26 reader independent.
11, use keypad to delete lost cards for safety.
12, Short-circuit protect: when relay or alarm output short circuit, it will shut up output in 100μS
RFID Standalone Access Control Technical parameters
Work Voltage |
AC&DC 9-28V |
Static Current |
≤30mA |
Reading Range |
3~8cm |
Capacity |
2000 users |
Environment Temperature |
-25~60 |
Electric lock output |
≤3A |
Alarm output |
≤20A |
Output short-circuit protection time |
≤100μS |
Open-door time |
0 ~ 99 seconds (adjustable) |
Waterproof degree |
IP68 |
Size |
120 *80*25mm |
1.Acousto-optic controled output ,anti-theft alarm inlay.can connect with alarm
2.Anti-theft device in machine
3.Can add sevral continuous card
Type: Card Frequency Reading-Card distance
W100 EM 125KHz 5-15CM
W100 13.56MHz 3-10CM
