Help CenterAUPAL Plasma Flame Cutting Machine With True Hole Function
Related Products
-
Hangzhou AUPAL Plasma Cutting Machine With True Hole Function Cutting MachineUS$ 1 - 1,000,000MOQ: 1 Set -
Hangzhou AUPAL 6000 Cnc Plasma Flame Cutting Machine With True Hole Function Cutting MachineUS$ 1 - 1,000,000MOQ: 1 Set
-
Hangzhou AUPAL 6000 Cnc Plasma Cutting Machine With True Hole Function Cutting MachineUS$ 1 - 1,000,000MOQ: 1 Set
-
AUPAL60003 Precision Table Style Galvanized Sheet True Hole Cutting MachineUS$ 1 - 1,000,000MOQ: 1 Set
-
AUPAL Precision 60002 Style Cnc Table Style Plasma True Hole Cutting MachineUS$ 1 - 1,000,000MOQ: 1 Set
Specifications
1.CNC Precision table cutting machine2.ISO 9001:2000
3.Machine size:2000*4000mm,2500*6000mm,2500*7000mm
4.Special groove
1. Basic components
Machine specification |
2000mm |
Track length |
4000mm |
Capacitance height-regulating device |
1set |
CNC Plasma torch |
1set |
Drive mode |
Double drive |
Driving system*dynamo |
Japan Panasonic servo |
CNC system |
American Hypertherm |
Gear box |
Germany |
Automatic Programming, Nesting software |
FastCAM Nesting Software |
Plasma Power (American) |
/ |
Precision cutting table |
1set |
Water table |
1set |
2Function components
Programming software (FastCAM professional made in Australia) |
1set |
Motorized plasma torch height capacitor sensor (China) |
1set |
3Main technical specifications
Max effective cutting width |
1500mm |
Max effective cutting length |
3000mm |
Rapid speed |
0-9000mm/min |
Max plasma cutting thickness (edge cutting) |
/ |
Max plasma perforation thickness |
/ |
|
|
|
|
Plasma cutting speed |
50-5500mm/min |
Torch lifting distance |
150mm |
Straight line positioning precision |
±0.2mm/10m |
Straight line repeat precision |
±0.2mm/10m |
|
Complete machine synthesis precision(the synthesis photo as standard )length of side(4 sides)1000X1000 live wire speed 500-800mm/min |
|
Length of a side (4 sides) |
±0.3mm |
Diagonal discrepancy/AD-BC |
±0.3mm |
Node discrepancy |
±0.3mm |
Back to the origin of deviation |
±0.2mm |
The deviation of along and reverse line |
±0.2mm |
Cutting surface roughness |
Rz(um)=70+1.2a roughness for sight measure: 12.5 |
Verticality and gradient tolerance |
μ(mm)=0.4+0.015a |
Running non-straightness |
Vertical line≤±0.2mm/effective length Horizontal line≤±0.2mm/effective length |
Arcing time factor |
80% |
Lineation precision |
≤0.3mm |
Torch angle error |
≤±0.5° |
4 Working environment
Environmental temperature |
0-50°C |
Humidity |
<90%, no condensation |
Surroundings |
Ventilation, no big shake |
Power voltage |
3×380V±10% / 50HZ |
Power frequency |
220V±10% / 50HZ |
Input power |
3KW |
