AUPAL 4 Metal Sheet Cutting Machine

Name: AUPAL 4 Metal Sheet Cutting Machine
Brand: AUPAL
SKU: 114304041
Availability: InStock

US$ 1 - 1,000,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, CNC

CNC or Not:

CNC

Hangzhou Aupal Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, CNC

CNC or Not CNC

Place of Origin Zhejiang, China

Brand Name AUPAL

Model Number CNCDG

Specifications

1.CNC Precision table cutting machine
2.ISO 9001:2000
3.Machine size:2000*4000mm,2500*6000mm,2500*7000mm
4.Special groove

1. Basic components

Machine specification	2000mm
Track length	4000mm
Capacitance height-regulating device	1set
CNC Plasma torch	1set
Drive mode	Double drive
Driving system*dynamo	Japan Panasonic servo
CNC system	American Hypertherm
Gear box	Germany
Automatic Programming, Nesting software	FastCAM Nesting Software
Plasma Power (American)	/
Precision cutting table	1set
Water table	1set

2Function components

Programming software (FastCAM professional made in Australia)	1set
Motorized plasma torch height capacitor sensor (China)	1set

3Main technical specifications

Max effective cutting width	1500mm
Max effective cutting length	3000mm
Rapid speed	0-9000mm/min
Max plasma cutting thickness (edge cutting)	/
Max plasma perforation thickness	/


Plasma cutting speed	50-5500mm/min
Torch lifting distance	150mm
Straight line positioning precision	±0.2mm/10m
Straight line repeat precision	±0.2mm/10m
Complete machine synthesis precision(the synthesis photo as standard )length of side(4 sides)1000X1000 live wire speed 500-800mm/min
Length of a side (4 sides)	±0.5mm
Diagonal discrepancy/AD-BC	±0.5mm
Node discrepancy	±0.5mm
Back to the origin of deviation	±0.2mm
The deviation of along and reverse line	±0.2mm
Cutting surface roughness	Rz(um)=70+1.2a roughness for sight measure: 12.5
Verticality and gradient tolerance	μ(mm)=0.4+0.015a
Running non-straightness	Vertical line≤±0.2mm/effective length Horizontal line≤±0.2mm/effective length
Arcing time factor	80%
Lineation precision	≤0.5mm
Torch angle error	≤±0.5°

4 Working environment
