Specifications
Highly quality: luxurious appearance (copper outside or stainless steel outsider).CE,ISO, BV certificates
Low energy.
We are one of the the best professional manufacturer and agent of beer equipment in our city with many years of experience. We specialize in personally manufacturing micro beer equipment , beer testing equipment and beer brewery plants, and more.
We also manufacture all types and sizes of fermenting and storage tanks.
Stainless steel conical Fermenter tanks
Control method |
Single pot single control |
Temperature control |
Hand/stop/automatic temperature control |
Heat exchange area(cooling jacket) |
0.6m2 |
Polishing precesion |
< 0.4, 0.6 Ra |
Cooling liquid |
Glycol water or alcohol |
Cleaning device |
CIP sprall ball |
Inner thickness |
2.0-3.0 mm |
Welding process |
Argon arck welding |
Outsourcing thickness |
1.5 mm |
Insulation |
polyurethane foam |
Design pressure |
0.3 MPa |
Pressure control |
Automatic pressure control |
Working pressure |
0.15-0.2 Mpa |
Sampling methods |
Clamps quick sampling valves |
Simply introduction:
-The classical shape: dished head and coned bottom.
-The angle of the -cone-shaped bottom is 60-72. Man way on the top.
-The inside finish is polished to 2b grade surface and the cladding is polished to mirror surface or frosted surface.
-The material is s.s.304 sheet, stainless steel.
-Insulation is polyurethane foam, which is full of the side and bottom. The sandwich is 80 mm thickness, which has many glycol jackets.
- 20%-25% excess headspace
- 3 S.S. legs with adjustable/un-adjustable footpads option
- Standard-sized side man way.
Fitting
- Bimetal thermometer
- Rotating sanitary CIP spray ball on inner head, down-tube
- One sampling cock (DIN20)
- Pressure gauge and a butterfly valve (DIN32) on the CIP down-tube - Pressure control method with hand or electro connecting pressure gauge optional
- 1 sanitary manual butterfly valve (DIN25) on the cone bottom for beer outlet
- 1 sanitary manual butterfly valve (DIN32) on the bottom for inlet of wort, collecting yeasts, and drainage
- All 3 butterfly valves
Our Commitment :
- 3 years warranty
- Free installation and training and maintenance in warranty
- Out surface mirror polishing.
- The material can be stainless steel with low price or red copper with nice-looking
- The capacity can be 50L~30,000L
- We will try our best to make you satisfied .sincere walks the world , faith make the foundatio.
We can manufacture any type that you want, if you contact us.
Our advanced technology and best after-sales service make us acquired goodwill and many customers, we also offer our professionals to help you solve the questions that you come across in your using.
QIDONG Company would like to devote our sincere attitude, good credit, best quality and perfect service, to cooperate with all clients, to set up our mutual bright future. And we have full lines with beer equipment that other manufactures could not match in China.
Believing us and choosing us and contacting us, you will find that we are the best one as a kindly business friend
