3000l large beer fermenter / fermenter tank

Specifications

Luxury appearance: stainless steel outsider, mirror surface.
CE,ISO, BV certificate
Low energy.
Conical fermenter



Specification:



Control method	Single pot single control	Temperature control	Hand/stop/automatic temperature control
Heat exchange area(cooling jacket)	0.6m2	Polishing precesion	< 0.4, 0.6 Ra
Cooling liquid	Glycol water or alcohol	Cleaning device	CIP sprall ball
Inner thickness	2.0mm	Welding process	Argon arck welding
Outsourcing thickness	1.5 mm	Insulation	polyurethane foam
Design pressure	0.3 MPa	Pressure control	Automatic pressure control
Working pressure	0.15-0.2 Mpa	Sampling methods	Clamps quick sampling valves
























-The classical shape: dished head and coned bottom. The angle of the -cone-shaped bottom is 60-72. Man way on the top.
-The inside finish is polished to 2b grade surface and the cladding is polished to mirror surface or frosted surface.
-The material is s.s.304 sheet, stainless steel.
-Insulation is polyurethane foam, which is full of the side and bottom. The sandwich is 80 mm thickness, which has many glycol jackets.
- 25% excess headspace
- 3 S.S. legs with adjustable/un-adjustable footpads option
- Standard-sized side man way.
Fitting
- Bimetal thermometer
- Rotating sanitary CIP spray ball on inner head, down-tube
- One sampling cock (DIN20)
- Pressure gauge and a butterfly valve (DIN32) on the CIP down-tube - Pressure control method with hand or electro connecting pressure gauge optional
- 1 sanitary manual butterfly valve (DIN25) on the cone bottom for beer outlet
- 1 sanitary manual butterfly valve (DIN32) on the bottom for inlet of wort, collecting yeasts, and drainage
- All 3 butterfly valves

We can manufacture any type that you want, if you contact us.
