SRP90S Road Machinery 9m Paver

Name: SRP90S Road Machinery 9m Paver
Brand: Shantui
SKU: 114297017
Availability: InStock

US$ 1 - 2 MOQ: 1 Set

Key Specifications

Condition:

New

Production Capacity:

800t/h

Power(W):

148kw/2300rpm

Shandong Dorson Hydraulic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Production Capacity 800t/h

Power(W) 148kw/2300rpm

Max. Paving Thickness 350mm

Paving Width 3-9m

Place of Origin Shandong, China

Brand Name Shantui

Model Number SRP90S

Dimension(L*W*H) 7800*9000*3800

Weight 28T

Certification ISO9001 CE

Warranty 1 Year

After-sales Service Provided Overseas service center available

SRP90S road machinery 9m paver

Product Description

Introduction:

SRP90S Multi-functional elescopic paver

SRP90S Multi-functional elescopic paver mainly used for paving of each grade road and asphalt concrete pavement material and foundation stability.Adopt microcomputer control system, electronic automatic leveling, continuous failure check function, dual vibrating, eccentric vibration advanced technologies. great drive power, paving stability is good, preloading high density, simply operation. Plate adopts hydraulic telescoping, paving width can be in the range of 3.0 meters to 6.0 meters, stepless adjustable, can adapt to different working condition, meet different customer needs.

Technical specification:

Dimensions:L×B×H(mm)	7800×9000×3800
Shipping sizeL×B×H(mm)	7800×3000×3360
Grass paving width / Maximum paving width (m)	3/9
Paving thickness (mm)	350
Hopper Capacity(t)	14
Gradeability (%)	20
engine	Deutz:BF6M1013EC Shangchai:SC8D190G2B1
Power (kW)/ Rotating speed (rpm)	148/2300
Heating Type	Centralized control heating
Main vibrator stroke (mm)	5
Deputy vibrator stroke (mm)	0,5,10
Vibration frequency (Hz)	0~50
Machine total weight / Maximum working capacity (t)	23/28
