wet Strong magnetic GTLH series Vertical Ring High Gradient Magnetic Separator with Separating Weak Magnetic Minerals
Annie Chang | Sales Manager
Dongjing Road East, Cell/ WhatsApp: +86 13356713809
Economic Development Zone, Wechat/zalo:+86 13356713809
qingzhou city , 262500, China Mail: yujuan391@163.com
Weifang Guote Mining Equipment Co., Ltd
We use the best quality, most favorable price, timely delivery period and the best after-sales service to meet every customer is our only aim.
A summary:
This product is applicable to 1.2 mm (- 200Mesh 30-100%) of fine non-metallic mineral, such as quartz, feldspar, nepheline ore, kaolin, iron removal purification. Can also be used for red iron ore (hematite, limonite and siderite, etc.), manganese ore, ilmenite, black tungsten, a variety of weak magnetic ore wet separation and black and white tungsten separation, black tungsten and tin separation.
GTLH Series high gradient magnetic separator is a new product developed independently by GUOTE. It combines the characteristics of international advanced high intensity magnetic separators, which is so far the high intensity magnetic separator of best performance and most advanced technology. This product utilizes vertical ring rotation, pulsating beneficiation and high frequency vibrator, and it has no magnetic medium jam problem in flat ring high intensity magnetic separator and flat ring high gradient magnetic separator.
It has the advantages of large beneficiation ratio, high security and convenient operation etc. This product realizes both high beneficiation ratio and high recycle ratio in separating weak magnetic minerals.
Frist ,Features of GTLH series Vertical Ring High Gradient Magnetic Separator:
1.Its separation ring is designed to be vertical,fine ore is discharged by reverse flow and also with separation pulse device .
2.Powerful magnetic force, reliable and Series GTLH Vertical High Gradient Magnetic Separator science performance
3. Simple installation and easy to maintain
4.Collecting and discharging continuously Long-term trouble-free operation
Second ,Application field of GTLH series Vertical Ring High Gradient Magnetic Separator:1. Updating Ferrous Metals: Martite, Hematite, Siderite, Chromite, Ilmenite, Manganese, Etc.
2. Separating Non-Ferrous Metals: Wolframite and Quartz, Pyrrhotite and Cassiterite, Wolframite and Cassiterite, Limonite Purifying, Scheelite, Wolframite and Garnet, Etc.
3. Recovering Rare Earth: Tantalum and Niobium, Lepidomelane, Monazite, Etc.
4. Brightening Non Metals: Quartz, Feldspar And Kaolin for Ceramics, Sillimanite, Cassiterite, Andalusite, Kyanite for Refractory, and Separating Impurities From Hornblende, Mica, Tourmaline, Garnet, Etc.
Third, Technical parameter of GTLH series Vertical Ring High Gradient Magnetic Separator:
Fourth,Technical features:
1. Vertical Ring Rotation & Pulsating Beneficiation
2. High Frequency Vibration Mechanism
3. Wide Range of Feed Particle Size
4. Multi-Gradient Matrixes & Liquid Level Control System.
These technologies improve the grade of magnetic concentrate and recovery.
5. Frequency Conversion Step-less Adjustment for Rotary Speed & Vibrating Frequency.
6. No Stepper Phenomenon of Rotary Rings
Fifth , Equipment scene photos of GTLH series Vertical Ring High Gradient Magnetic Separator:
1.Equipment painting completed before shipment, With Stretch film to avoid rub off the surface paint, It can used wooden cases packaging according to users requirements.(Key parts such as electric cabinet with shockproof packaging material and then packed in wooden cases. )
2. We have 15 experienced engineers, With 108 skilled workers insure good quality of our machines and prompt delivery.
3.Meanwhile our company has a long-term cooperation with ACL, CSCL, CCNI,CNC, COSCO etc insure the goods to the port on time
Our service
1. Our engineers can work separately according to the requirements of design for clients of the equipment. and send a customer confirmation to help customers to save costs.
2. During the manufacture of the equipment, we photograph product production progress, and sent to the customer to track the progress.
3. The goods hair go, we will send the original documents for the customer (such as packing list, bill, CO, Form E, Form A, Form F, Form M, B/L etc.)
4. We can provide customers with free English foundation drawing, installation drawings, manuals, maintenance manuals and parts drawings.
5. We can send our engineers to installation and debugging overseas, and free training of operators and maintenance workers.
6. We have a set of After-sales service system, A ID will be sent to each customer, they can log in this system that view all information to buy equipment and parts by it. We provide 24-hour online consultation.
1. During the installation and commissioning, we shall send our technician to the site for guiding the installation and commissioning.
2. During the installation and commissioning, we offer training service
3. The quality assurance date is one year after commissioning.
4. If the equipments appear the equipment failure because of improper handling of user, we are in charge of maintenance, and collect the appropriate cost.
5. We offer the components with favorable price, perdurable maintenance. After quality assurance date, if the equipments need to be repaired, we only collect the cost price.
