Specifications
LED panel light,Energy saving Long life
Instant ON/OFF operation
Soft light
Environment-Friendly,Lead and Mercury
Special Features:
1. Quality Driver with 3-year warranty(Taiwan Meanwell driver)
A, High EMC, no interfere
B, Power factor>0.95
C, Power Efficiency>90%
D, UL, TUV, PSE compliance
E, Full protection: short circuit, over voltage, over current and over temprature
2. High-performance Original EDISON LED (Made in TaiWan) and perfect wiring design
It has High CRI and High lumens and high reliability. Even if one led failed, the remaining LEDs will still work.
3, Safety
A, CE, RoHS, PSE, FCC, C-TICK
B, 4000V Hi-pot test pass
4,Warranty Policy
3 years warranty with free collection and free delivery. For any defects, we will solve it by either
repairing any defective parts or replace a new LED grille light. (For more details, please ask for
Warranty Statement)
5. Low Light Loss
The light source is the low light loss and high-bright LED, which the loss is less than 5% in 10,000 hours.
The aluminum back-side housing performs an excellent heat dissipation, which guarantees a lower junction
temperature of the LED, thus slow down light loss.
6. Environment-Friendly
While working, no ultraviolet light and infrared light radiation. And never contain any hazardous substance,
such as Mercury.
7. Anti-vibration
Solid-state,anti-vibration, not easy to be broken. Can be recessed mounted or work as a pendant.
Application:
1.Office lighting
2.Hotel lighting
3.Super market lighting
4.Warehouse lighting
5. Airport lighting
6.Factory lighting
7.Classroom lighting
Technical Specification:
Part No. |
Main Spec. |
|
|
CA-PL3014WF2-52W (600*600mm) |
Working power |
50w±10% |
Input voltage |
AC85V-265V |
|
Working frequency |
50-60Hz |
|
Luminous flux |
4000-4200Lm |
|
power factor |
>0.95 |
|
CRI |
>80 |
|
Color Temperature (CCT) |
Cool white : 5700K±500K Nature white: 4000K±400K Warm white : 3000K±300K |
|
Material |
Alu frame/guide plate |
|
Size |
600mm*600mm |
|
Working temperature |
-30~+40°C |
|
Storage temperature |
-40~+80°C |
|
Light Frequency |
80Lm/W |
|
Light distribution Curve ( IES File available, please contact us )
Caution & Warning
1.Use indoor or some place where no water.
2.Work under the fixed voltage.
3.Pls operate in the right way when you install the LED panel light in case to avoid the power harm and body harm. When installing, please note the short-circuit protect such as the socket with the fuse.
4. non-dimmable
5, If any doubt about the installation or use of this product, consult a competent electrician or technician .
