JS200 Water well drilling rig, water well rig drilling machine portable
JS200 crawler deep hole drilling rig is a new,highly-effective,energy-saving ans multi-functional hydraulic drill and it is specialized in drilling hole for rock blasting,well,monitoring well,geothermal air conditioning hole,grouting hole of the hydropower cofferdam,grouting hole for dyke seepage control and grouting hole for base enforcement,surface mining,anchorage,national defense project and other drilling operations.The drill is equipped with hydraulic motor rotation with a high power,propulsion and lifting of cylinder and down-hole impacter with high blast pressure,to realize high effectiveness of drilling footage and low energy consumption.
Characteristics
1:The chassis is driven by highly-efficient pneumatic motor with powerful traction. Each track is driven independently by air motor with enclosed gear drive, the gradeability arrives 35degree with a compressor, or 50 degree alone.
2:Hydraulic track oscillation is more suitable for positioning drilling machine during drilling..
3:The carriage with rollers provides for minimal wear to the drill guide.
4:Equipped with two hydraulic clamps is easy to load and unload drilling rods and improve efficiency.
5:The special compensation device makes a full production of drill rod threads.
6:The Hydraulic auxiliary functions are easy and efficient for guide extension, boom swing, boom lift, guide tilt and guide dump.
7:Competitive in price,low cost of maintain.
Specification
| 1 | Rock Hardness | F=6-20 | |
| 2 | Hole Diameter | mm | 150-254 |
| 3 | Hole Depth | m | 200 |
| 4 | Max horizontaldrilling | m | 3.38 |
| 5 | Rotation Torque | Nm | 4000 |
| 6 | Rotation Speed | rpm | 0-100 |
| 7 | Rotation Power | KW | 18.34 |
| 8 | Max. pushing power | KW | 3.36 |
| 9 | Max. Lifting force | N | 80000 |
| 10 | Max. Feed Speed | M/min | 20 |
| 11 | Max. Lifting Speed | M/min | 20 |
| 12 | Manufacturer | CUMMINS | |
| 13 | Rated Horse power | Kw | 70 |
| 14 | Electrical System | 24 | Volt |
| 15 | Compressor Type | Rotary Screw/Movable | |
| 16 | Compressor Pressure Required | Mpa | 1.2—2.4 |
| 17 | Air consumption | m3/min | 11—32 |
| 18 | Volume of Flow | L/Min | 200 |
| 19 | Rated Pressure | Mpa | 1.6 |
| 20 | Max. Travel Speed | Km/h | 2.5 |
| 21 | Gradeability | degree | 15 |
| 22 | Net Weight | kg | 7100 |
| 23 | Shipping Length | mm | 6000 |
| 24 | Shipping Width | mm | 2100 |
| 25 | Shipping Height | mm | 3200 |
| 26 | Ground Clearance | mm | 300 |
| 27 | Guide Extension | mm | 1400 |
Packaging & Shipping
Standard sea transportation package or packed as customer's requirement
In our after sales service system, We establish perfect control system strictly according to ISO-9000 series, in this system, technology date and problem solve solution and preventive measures will be provided in any maintain project, all the spare parts will be used in new OEM products with installation instructions, packing list, manufacturer's instruction, qualification and Warranty certificate.
We provide "one equipment & one case, endless service, namely the after sales service begin from the order confirmation, last for the working life of the equipment.
Jincheng provide users high quality Mining & Drilling solutions,we always focus on the strategic conception of “Survival by quality, Development by credit’’.
We have specilized in research, development and produce of rock blasting drilling rig, water well drilling rig, diamond core drilling rig, anchor drilling rig, and relative accessories & drilling services. constantly provide professional drilling solutions for all customers with our advanced technology, excellent equipment, strict testing means and perfect service network, which establish our brand “JCTECH” a good image of market, now,we products account for 50% of domestic market and have been export to more than 40 countries, and we awarded ISO9001: 2000 in November,2002.
With excellent technology and solid market service capabilities, we have both a sound marketing system and excellent service support system, which help us win confidence of customers both at home and abroad,we can provide drilling rig users with high quality professional air compressor solution and relative after-sales service also.
Any question of us or our products please feel free contact us!
