Quality primacy good function 72a heat treatment galvanized steel wire
Main Technical Parameter of 72a heat treatment galvanized steel wire:
Furnace tube diameter: 850mm
Height of steel wire: 1500mm
Fuel: Diesel
Oil pressure: 1-2kgf/cm2
Burner quantity: 2 sets (Dislocation arrangement)
Oil consumption: 20kg/h
Power supply: 380V 50HZ
Furnace tube max using temperature: 750°C
Working temperature: 680°C~750°C
Temperature control section: 2 sections(up and down)
Temperature accuracy: ±10°C
High pressure air power: 3KW
Amount of wind: 500~600m3/h
Capacity: 1.2t per time
Pictures of 72a heat treatment galvanized steel wire:
About us:
Wuxi Pingsheng Science & Technology Co., Ltd. , one of the leading wire drawing machine manufacturers in China , is specialized in manufacturing wire drawing machines , which was established in 1985.
Our services:
1. We are always providing customers with not only the excellent solutions of steel wire production line, best related equipment and perfect services but also free technical services on the steel wire production line.
2. If you have any questions in the process of producing steel wire, or about steel wire production line, please feel free to contact us any time. Our solutions and quotation will be sent to you soon to meet you special requirements.
3. Welcome to visit our factory and Wire drawing production lines.
Successful experience / Markets:
Be up to the international level. Our lines and related complete equipment have been exported to Southeast Asia, West Asia, Eastern Europe, South America, the Middle East, Russia, India, Indonesia, Morocco, South Africa, Algeria, etc.
72a heat treatment galvanized steel wire
