Home > Products > LED Controller /Power supply > JBSYSTEMS Compact RGB Remote Control - Led Wall Dimmer
JBSYSTEMS Compact RGB Remote Control - Led Wall Dimmer
- Shengzhen
- T/T
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | JBSYSTEMS | |
| Model Number | LED Wall Dimmer |
Product Description
Specifications
led wall dimmer, remote control for led projector4 dmx ch, fits in recessed wall box
Item Name: RGB remote control
Item code:LED Wall Dimmer
Brand: JBSYSTEMS
:: Product Description
* Compact RGB remote control for LED projectors
* Extremely user-friendly and easy
* 2 user programmable scenes.
* Sends 4 standard DMX-channels: R + G + B + master dimmer
* Easy wall mounting, fits in any standard recessed wall box
* Perfect for use in LED installations for hotels, homes, shops, …
* Several wall dimmers can be combined together in bigger installations
* Comes with 2 different cover plates
* 3 different working modes for maximum flexibility.
:: Technical Information
* Power Input: DC 12V / 400mA.
* DMX outputs: wire terminals
* DMX channels:
* RGB1 mode:
* CH1 = RED (DMX-values : 000  255)
* CH2 = GREEN (DMX-values : 000  255)
* CH3 = BLUE (DMX-values : 000  255)
* CH4 = MASTER DIMMER (DMX-values : 000  255)
* RGB2 mode:
* CH1 = RED (DMX-values : 000  255)
* CH2 = GREEN (DMX-values : 000  255)
* CH3 = BLUE (DMX-values : 000  255)
* CH4 = MASTER DIMMER (DMX-values : 000  190)
* 2 CHANNEL mode:
* CH1 = DIMMER1 (DMX-values : 000  255)
* CH2 = DIMMER2 (DMX-values : 000  255)
* Size: cover plate = 83 x 83 mm
* Installation depth = 16 mm
* Weight: 60 g
