Specifications
General color cover version LED Neon Flex Stripe, ,R,G,B,Y,O, all color, High brightness LED Chip inside
Type1 General Version Color cover LED Neon Flex Stripe
1. Color cover jacket (highlight your signs and make it remarkable even in day time)
3. SLED General version (SLN30XX-II) is powered by General grade application for such as signs and background but in not so high request on illuminations!
4. SLED economical version (SLN30XX-I) is special design for those limited budget on signs and designs but with similar effect up to glass neon flex.
5. Voltage range 24V 120V, 240V.
6. LED Spacing: 0.5" or 1.27cm.
7. Package: By rolls. But the real length depends on the integer multiple unit length.
8. Color: R, G, B, O, Y,
9. Cross section27.5*14.5mm
Item name rule:
You have an easy way to get our item code.
For example, the gerneral color cover Version neon flex strip SLN3050, the last two number means length per roll.
Suffix -color and - voltage like SLN3050-R-110V or SLN3010-G-24V
Rome number (-I, -II,-III) is for LED grade the bigger number the more brightness. We use Economical and General and Professional as our classification
We defaultly use General grade for its LED source.
Technical Spec:
SLN3010/SLN3050
Length in roll
Length in roll
240V
10m R, Y, O: 6 units B, G, : 10 units
50m R, Y, O: 32 units B, G, : 54units
120V
10m R, Y, O: 12units B, G, : 20 units
50m R, Y, O: 64 units B, G, : 108units
24V
10m R, Y, O: 90units B, G, : 130 units
50m R, Y, O: 450 units B, G, : 650units
LED Qty /unit
240V R, Y,O : 120PCS B, G, : 72PCS
120V R, Y,O : 60PCS B, G, : 36PCS
24V R, Y,O : 8PCS B, G, : 6PCS
Cut unit length:
240V R, Y,O : 1.52m B, G, : 0.91m
120V R, Y,O : 0.762m B, G, : 0.457m
24V R, Y,O : 1.02m B, G, : 0.076m
Power Consumption:
240V R, Y,O : 3.15W/m B, G, : 3.94W/m
120V R, Y,O : 3.15W/m B, G, : 3.94W/m
24V R, Y,O : 3.15W/m B, G, : 3.94W/m
max loading by 1.6A convertor
240V R, Y,O : 122m B, G, : 97 m
120V R, Y,O : 60m B, G, : 48m
24V R, Y,O : 7.92m B, G, : 6.4m
light output
Color Red Yellow Orange Green Blue
Total output (Lm/Ft) 4.4 8.6 6.8 9 4
Accessories::
Plastic clip,
Channels: PC channel 2 m or mini Channel 5cm, Aluminum channel,
Front connector: Plug + power code + Transformer+ AC/DC convertor +front connector + male pin+shrink tube
Splice connector: male pin + shrink tube
Middle connector 2 female connector + 2 male pin + costumed cable
End connector: end cap
Glue
