China supplier best sale small wire nail making machine
- 1 Set / Sets per Month
- shanghai
- T/T
Product Details
Condition: | New | Type: | Wire Drawing Machine | Use: | Wire |
Place of Origin: | Jiangsu, China | Brand Name: | pingsheng | Model Number: | LT11/450 |
Voltage: | As design | Power(W): | As design | Dimension(L*W*H): | As design |
Weight: | 1.5-11T | Certification: | ISO9001:2008 | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
China supplier best sale small wire nail making machine
Description of small wire nail making machine:
Reducer of the machine applies 8-module herringbone gear and the gear of inlet box is 10-module with speed ratio of 1:1. Materia for axis of high-speed gear is high frequency quenching 40Cr. Tower wheel can be made from common cast steel #55, common cast steel 55# with high-frequency quenching, and common cast steel #55 painted by tungsten carbide according to customers' demand.Transmission bearings are all famous products. Charging system applied sectional coupling that obtain proper bearing of the axis. Reducer , wet box and charing box are on the same base for easy installation and lifting. The surface painting ia of high grade and both internal and external of electric-control cabinet applies plastic-spraying process. It is divided into commom control and variablr-frequency control. Electric parts are all Chinese or international famous brands.
Heavy wet drawing machine is one of our products with more than 20% market share of China and 50% market share of key districts.
parameters of small wire nail making machine:
Items Unit LT8/650 LT11/650 LT15/650-560 LT11/450 LT15/450 Capstan diameter mm 650 650 650-560 450 450 Max inlet diameter mm Φ8-Φ6.5 Φ8-Φ6.5 Φ6.5-Φ5.5 Φ4.5 Φ4.5 Min outlet diameter mm Φ3.7-Φ3.0 Φ2.7-Φ2.2 Φ1.6-Φ1.4 Φ1.7 Φ1.2 Inlet tensile strength Mpa ≤1150 ≤1150 ≤1150 ≤1150 ≤1150 Drawing speed m/min 200 250 280 260 300 Drawing dies time 8 11 15 11 15 Total compression rate % 78.7 88.54 93.94 85.73 92.89 Average compression rate % 17.58 17.88 17.05 16.22 16.16 Motor power Kw 160-132 160-132 132-110 90 75 Dimension mm 5800*2350*1800 5500*2200*1600 Weight T 11 9.5
Pictures of small wire nail making machine:
Company Information:
1. We have gotten ISO9001:2008 standard and certificate
2. Company established year: 1985
3. Company location: Wuxi city, 125km away from Shanghai
4. FOB port: Shanghai
5. Business type: Manufacturer
6. Number of employees: 100-200
7. Welcome to visit us, we will pick you up at Shanghai airport or other place near Wuxi
Our services:
1. We are always providing customers with not only the excellent solutions of steel wire production line, best related equipment and perfect services but also free technical services on the steel wire production line.
2. If you have any questions in the process of producing steel wire, or about steel wire production line, please feel free to contact us any time. Our solutions and quotation will be sent to you soon to meet you special requirements.
3. Welcome to visit our factory and Wire drawing production lines.
--------------------------------------------------------------------------
Successful experience / Markets:
Be up to the international level. Our lines and related complete equipment have been exported to Southeast Asia, West Asia, Eastern Europe, South America, the Middle East, Russia, India, Indonesia, Morocco, South Africa, Algeria, etc.
