Help CenterLED CONTROLLER(SLDC6004)
Related Products
Specifications
Output: DC 48V 350mAPower input: AC 100V-240V
Power consumption: 40W max.
Ingress protection: IP20
Size:125 x 79 x 194mm
Item Name: LED CONTROLLER PRO SERIES
Item Code: SLDC6001
This series LED controller is specially designed for Summitlite Commercial Bulb, Spot light , Path light , Aqua light, LED Wall Washer with 48V 380mA tri color technology or MR16 housing products. With its built-in programs and DMX mode, it can bring a very powerful and wonderful color effects.
We have 4 output power (SLDC6004) and 1 output (SLDC6001) power control unit for MR16 LED series range of products. Compact and easy to use.
Product feature.
* 400Hz LED frequency, flicker free
* One/Four outputs power and signal unit
* Compact and rugged construction
* 4 modes: Auto, Sound, DMX, Master/Slave
* 18 colors preset + 3 built-in programs
* Smooth dimming 0-100%
* Variable strobe 0-20 fps
* Wireless remote (optional)
* Output ports of 36 watts each
* DMX control using 6, 12, 18, or 24 channels
* Software updateable via USB port
* LCD digital display menu for all settings
* Remote access to stand alone features from DMX
* Can be wall mounted, free standing, or clamp mounted.
Technical infomation:
Output: DC 48V 350mA
Power input: AC 100V-240V
Power consumption: 40W max.
Ingress protection: IP20
Size:125 x 79 x 194mm
Weight:1.60kg
