Digital Amplifier Module APL-12

Digital Amplifier Module APL-12 thumbnail-1
Digital Amplifier Module APL-12 photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
JBSYSTEMS
Model Number:
APL-12
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Summitlite International Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name JBSYSTEMS
Model Number APL-12
Place of Origin Guangdong, China

Specifications

APL Series Class-D Amplifier module for installation inside PL-series plastic speakers,
very easy installation inside .

Item Name: Digital Amplifier Module

Item Code: APL-12

Brand: JBSYSTEMS



JBSYSTEMS APL Series Class-D Amplifier module for installation inside PL-series plastic speakers, very easy installation inside JB Systems(R) passive PL-series, APL-12 High output power: 190Wrms @ 8ohm ~ 300Wrms @ 4ohm.



:: Product Description



     * Class-D amplifier module for installation inside PL-series plastic speakers

     * Very easy installation inside JB Systems(R) passive PL-series (version 2009)

     * High output power: 190Wrms @ 8ohm ~ 300Wrms @ 4ohm

     * Treble/bass tone controls + master volume.

     * Balanced / unbalanced microphone input (jack + XLR) with volume control

     * Balanced / unbalanced line input/output (XLR) with volume control.

     * Speakon output for optional passive 8ohm cabinet.

     * IEC input mains connector with integrated switch.



:: Technical Information



     * Power 4 ohm: 300Wrms

     * Power 8 ohm: 190Wrms

     * Freq. Resp. (+/-1.5dB): 20 - 20.000Hz

     * THD (1kHz / 1W): 0,12%

     * Input Sensitivity line: 1V

     * Input Sensitivity micro: 15mV

     * Input impedance: 20 kohm

     * S/N ratio (mic off) >87dB

     * EQ low: +/-12dB @ 100Hz

     * EQ high: +/-12dB @ 10kHz

     * Cooling: natural air cooling

     * Microphone input: Bal/unbal XLR/Jack

     * Line input: Bal/unbal XLR 3pin

     * Outputs Speakon: +1/-1

     * Protections: Thermal, Limiter, Current limiter, short circuit, DC-protection

     * Fuse: (5x20mm) T6,3A / 250V

     * Power supply: AC230V / 50Hz

     * Dimensions (mm): 276x173x 45mm

     * Hole cutout (mm): 250x145mm
