Good quality most competitive china wire drawing machines
- 200 Set / Sets per Month
- Shanghai
- T/T
Product Details
Condition: | New | Inlet Diameter: | 5.5-12m | Outlet Diameter: | 5-10m |
Place of Origin: | Jiangsu, China | Brand Name: | PS | Model Number: | DL1600 |
Voltage: | 380/415/440/220 | Power(W): | 22-45kw | Dimension(L*W*H): | 2.1*1.6*1.7M |
Weight: | 8160KGS | Certification: | ISO9001-2008 | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Good quality most competitive china wire drawing machines
Description of china wire drawing machines:
Inverted Vertical Drawing Machine is developed for the non-slip drawing of medium&low carrbon steel wire, special shaped steel wire and nonferrous metals with thick & medium diameters.
It is especislly suitable for the drawing of medium & low carbon steel wire in standard parts and supermaket shelf industriy.
The maximum inlet diameter can reach 40mm and diameter of capstan is 550-1400mm.
Transmission part of the system can apply cycloidal speed reducer, harden gear surface reducer or rocker reducer. Its electric system applies international famous brand frequency converter with performance.
Features of china wire drawing machines:
1. It is applicable for continuous production process of coil with heavy charing box.
2. Easy operation and reliable control enables safe production and conveninent maintenance.
3. Application of 3-phase AC variable-frequency speed adjustment realizes smooth stepless speed regulation and saves more than 30% electric power.
parameters of china wire drawing machines:
Items | Unit | DL1600 | DL1400 | DL1200 | DL1000 | DL800/700 | DL600/560 |
Capstan diameter | mm | 1600 | 1400 | 1200 | 1000 | 800/700 | 600/560 |
Max inlet diameter | mm | Φ40 | Φ32 | Φ25 | Φ18 | Φ12 | Φ8 |
Inlet tensile strength | Mpa | ≤900 | ≤900 | ≤1150 | ≤1150 | ≤1150 | ≤1150 |
Drawing speed | m/min | 20-30 | 30-45 | 30-60 | 30-75 | 30-90 | 60-120 |
Total compression rate | % | 15-30 | 15-30 | 15-30 | 15-30 | 15-30 | 15-30 |
Motor power | Kw | 120-180 | 100-145 | 90-132 | 75-120 | 45-100 | 22-75 |
Pictures of china wire drawing machines:
Company Information:
1. We have gotten ISO9001:2008 standard and certificate
2. Company established year: 1985
3. Company location: Wuxi city, 125km away from Shanghai
4. FOB port: Shanghai
5. Business type: Manufacturer
6. Number of employees: 100-200
7. Welcome to visit us, we will pick you up at Shanghai airport or other place near Wuxi
Our services:
1. We are always providing customers with not only the excellent solutions of steel wire production line, best related equipment and perfect services but also free technical services on the steel wire production line.
2. If you have any questions in the process of producing steel wire, or about steel wire production line, please feel free to contact us any time. Our solutions and quotation will be sent to you soon to meet you special requirements.
3. Welcome to visit our factory and Wire drawing production lines.
--------------------------------------------------------------------------
Successful experience / Markets:
Be up to the international level. Our lines and related complete equipment have been exported to Southeast Asia, West Asia, Eastern Europe, South America, the Middle East, Russia, India, Indonesia, Morocco, South Africa, Algeria, etc.
china wire drawing machines
