Help CenterQ3210 Dustless Shot Blasting Machine With High Quality Blast Wheel From China Supplier
Related Products
-
2016 New Techology Q32 Series Dustless Rubber Tracked Shot Blasting Machine PriceUS$ 6,000 - 20,000MOQ: 1 Set -
CE Approved Hanger Chain Shot Blasting Machines PriceUS$ 20,000 - 250,000MOQ: 1 Set
-
Q38 Series Overhead Rail Spinner Hanger Shot Blasting MachineUS$ 20,000 - 250,000MOQ: 1 Set
-
Concrete Floor Shot Blast Equipment Made in ChinaUS$ 28,000 - 40,000MOQ: 1 Set
-
Portable Dustless Blasting Machine PriceUS$ 2,500 - 6,000MOQ: 1 Set
This machine is a cleaning effect, compact structure, low noise, complete and good cleaning equipment with a comprehensive domestic and foreign technology,design and development of new products.This machine is widely used in spring plant,tool plant,heat treatment workshop,foundry and stamping workshop.
The color rendering is as below.
Item |
Unit |
Q326C |
QR3210 |
QR3220 |
Productivity |
t/h |
0.6-1.2 |
1.5-2.5 |
3.0-4.5 |
Feeding amount |
kg |
200 |
600 |
1000 |
Max. weight of single piece |
kg |
10 |
30 |
50 |
Diameter of end disk |
mm |
650 |
1000 |
1000 |
Effective volume |
m3 |
0.15 |
0.3 |
0.8 |
Abrasive flow rate |
Kg/min |
100 |
250 |
2x18 |
Ventilation capacity |
m3/h |
2200 |
5000 |
10500 |
Power consumption |
kw |
12.6 |
24.3 |
44.9 |
Outline dimension |
mm |
3681*1650*4200 |
3927*2600*4768 |
5050x3085x6200 |
1) blaster has a long life, simple structure, low failure rate
2) winnowing separator has a good separation effect and higher productivity, to improve the life of the blade
3) the layout of Shot Blasting chamber body have undergo three-dimensional computer
simulation of dynamic projectile
4)there has reinforcing rib outside of the chamber,thus to make the machine stable and strong when working.
5) cleaning room adopts wear protective sheeting with long-life and beautiful appearance,easy
to replace.
1)Polishing small casting,forging,metal stamping, spring,auto parts and so on
2)Cleaning old oxide,rust,rag
3)Strengthening surface of work pieces
1.Payment item
1.T/T,30% deposit, 70% before shipment
2.L/C irrevocable LC at sight
2.MOQ
1 PCS
3.Delivery time
Depond on the machine, 30 days usually.
