pvc pipe production line/PVC pipe extrusion line
Specifications
pvc pipe production line/PVC pipe extrusion line
1>Conical double screw extruder
2>16-63mm,75-25;400-630mm
pvc pipe production line/PVC pipe extrusion line
Application :
Drainage water and water supply pipe in construction field.
Drainage water and water supply pipe in agriculture field.
Drainage water and water supply pipe in industrial field.
Wire and electrical cable protection pipe
Multi-function pipe.
This line is use CPVC material, have many dimension.Such as: GF63;GF110;GF160;GF250;GF400;GF630,and so on.
pvc pipe production line/PVC pipe extrusion line
Process flow
CPVC powder + additive → mixing → spring feeding → twin screw extruder → mould and calibrator →
vacuum forming machine → haul off machine → cutting machine → discharging rack
pvc pipe production line/PVC pipe extrusion line
Technical Parameters:
Model number |
PVC-16/63 |
PVC-20/110 |
PVC-50/160 |
PVC-75/250 |
PVC-110/315 |
PVC-200/450 |
PVC-315/630 |
PVC-500/800 |
Pipe diameter |
16-63mm |
20-110mm |
50-160mm |
75-250mm |
110-315mm |
200-450mm |
315-630mm |
500-800mm |
Max output |
120kg/h |
120kg/h |
180kg/h |
300kg/h |
450kg/h |
650kg/h |
800kg/h |
1400kg/h |
Production rate |
1.5-15m/min |
0.8-8m/min |
0.5-5m/min |
0.4-4m/min |
0.3-2m/min |
0.1-1m/min |
0.07-0.7m/min |
0.05-1 m/min |
Extruder model |
SJZ-50/105 |
SJZ-50/105 |
SJZ-55/110 |
SJZ-65/132 |
SJZ-80/156 |
SJZ-92/188 |
SJZ-92/188 |
SJZ-105/220 |
Installed power |
45kw |
45kw |
55kw |
75kw |
105kw |
160kw |
205kw |
305kw |
Center height |
1000mm |
1000mm |
1000mm |
1000mm |
1100mm |
1100mm |
1200mm |
1350mm |
Installation area |
22*2.5*2.0m |
24*2.8*2.0m |
24*2.8*2.0m |
30*2.8*2.2m |
35*3.0*2.4 m |
36*3.0*2.4 m |
38*3.2*2.8 m |
42*3.5*3.2 m |
