Large Ice Cube Machine for Eating Daily Capacity From One Ton to Twenty Tons

Name: Large Ice Cube Machine for Eating Daily Capacity From One Ton to Twenty Tons
Brand: CBFI
SKU: 114179537

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Capacity:

1000kg/ per day

Place of Origin:

Guangdong, China

Brand Name:

CBFI

Guangzhou Icesource Refrigeration Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Capacity 1000kg/ per day

Place of Origin Guangdong, China

Brand Name CBFI

Model Number CV1000

Ice Shape Other, Cube Ice

Certification CE

Specifications

1.Ice cube: edible ice, widely used in hotel, restaurant , bar
2.Ice shape: small cube, clean ,nice
3.automatical falling ice

Large ice cube machine CV series

Ice cube have two size : 22mm*22mm*22mm; 29mm*29mm*22mm
Daily capacity: from 1 ton to 20 tons.
Large production: its production can reach 95% to 98%. If environment temperature low than 23°C , production can reach 100% to 130%.
Lower power consume: it power consumption only about 80 k w produce 1 ton ice, if environment temperature is lower than 23 °C, power consumption is from 70k w to 75 k w.
Easy operation: adopt PLC program controller central control, automatically adjust ice thickness, automatically supply ice making water, no need manually adjust.
Space saved: machine unit adopt integrated design, structure is very compact.

Ice Cube Machine Models for Your Reference:

Item No.	Production	Compressor Rated Power	Circulating Water Pump Power	Cooling Water Pump Power	Cooling Fan Power	Machine Dimension	Weight of Machine
	Ton/24H	KW	KW	KW	KW	LWH	KG
CV1000	1.0	3.69	0.37	1.5	0.37	120010001600	800
CV2000	2.0	7.11	0.37	1.5	0.55	163016001686	1000
CV3000	3.0	9.68	0.37	2.2	0.75	198016301840	1200
CV5000	5.0	17.47	0.55	2.2	1.5	289017801840	1600
CV8000	8.0	28.52	1.1	4	1.5	482017802000	2500
CV10000	10.0	37.68	1.1	4	1.5	573017802000	3000
CV15000	15.0	52.41	1.65	5.5	2.2	862017802000	4500
CV20000	20.0	75.36	2.2	8	3	1146017802100	6000
