Commerical Edible Ice Tube Maker With High Technology Evaporator

Specifications

The working theory of large tube ice maker:

After the large tube ice machine normal working, the water in the bottom water bin take form the outlet pumped to the inlet of the upper water bin by the chilling pump, and then through the water segregator as a screw flow way along the inner wall of the recuperator tube flowing downward with the refrigerant on the surface of recuperator tube doing heat exchange, then the temperature is reduced, parts of water will be formed ice tube in the inner recuperator tube, the water that don't formed ice after fall of temperature will be flowing into the bottom water bin, the water circulating again and again, so the cold energy will loss just a little.

After a certain time, the water stops circulated, the tube ice machine changes into ice dropping model, ice cutting structures running, the refrigeration on surface of the trcuperator tube will be turned into high pressure refrigerant gas, the heat gas exchange heat with the ice tube in the ice maker and make the ice tube melt little ,then the ice tube without the gravity, slide down into the ice cutting structure, and cut ice tube to small tubes.

Tube ice is a kind of hollow cylindrical ice with external diameter28mm,30mm and length 25~42mm. The hole diameter is usually 5~10mm and it can be adjusted according to ice making time.

Tube ice is crystal and transparent with long storage period. It isn't likely to melt in a short time,good air permeability. It can be directly eaten or used to freeze drinks, mix wines, cool foodstuffs, make ice pastries and keep fresh, ect.

Large tube ice machine features:

1. Perfect design: large tube ice machine adopts 3D simulation assembly, compact structure, easy operate and maintain.
2. Sanitary: the material for large tube ice machine’s evaporator is seamless SUS304 tube, and adopts big rounded excessive design, everywhere of the machine is easy to clean.
3. Efficient performance: Tube ice machine uses special alloy material and with special heat treatment, makes the ice maker with best thermal performance.
4. Full automatically: PLC system controls the whole ice making process.

If you are interested in our products, please contact us. We would be very glad to be on service for you. As the most professional ice machine manufacture in China, we are pleased to do our best offer to open a good market for you. We are definitely to contact you within 3 days after getting your inquiry.

Large Tube Ice Machine for Drinks and Wine:
