5 Tons Ice Tube Machine
Tube Ice Machine Description
1.Tube ice machine daily capacity from 1 ton to 20 tons.
2.Tube ice is a kind of hollow cylindrical ice with external diameter 16mm ,22mm, 28mm, 35mm and length 25~42mm . The hole diameter is usually 5~10 mm and it can be adjusted according to ice making time.
3.Perfect design: adopt 3D simulation assembly, compact structure, easy operate and maintain.
4.Health: ice maker adopt SUS 304, PE, and aluminum material to process, and adopt big rounded excessive design, everywhere of the machine is easy to clean.
5.Fully automatically: PLC system controls the whole ice making process.
6.Application: it can be directly eaten or used to freeze drinks, mix wines, cool foodstuffs, make ice pastries and keep fresh ect.
Main model for commercial tube ice machine:
Item No. |
Production |
Compressor Rated Power |
Circulating Water Pump Power |
Cooling Water Pump Power |
Cooling Fan Power |
Ice Cutter Motor Power |
Machine Dimension |
Weight of Machine |
|
Ton/24H |
KW |
KW |
KW |
KW |
KW |
L*W*H |
KG |
TV10 |
1.0 |
3.69 |
0.37 |
1.1 |
0.18 |
0.75 |
1320*950*1800 |
900 |
TV20 |
2.0 |
7.11 |
0.55 |
1.1 |
0.18 |
0.75 |
1400*1100*1800 |
1200 |
TV30 |
3.0 |
9.68 |
0.55 |
1.1 |
0.37 |
0.75 |
1500*1100*1950 |
1500 |
TV50 |
5.0 |
17.47 |
0.55 |
1.5 |
0.75 |
0.75 |
1600*1250*2200 |
1800 |
TV100 |
10.0 |
30.89 |
0.75 |
2.2 |
1.5 |
1.5 |
1700*1300*2200 |
3500 |
TV150 |
15.0 |
42.6 |
1.5 |
2.2 |
2.2 |
1.5 |
3000*1500*2200 |
4250 |
TV200 |
20.0 |
53.2 |
1.5 |
2.2 |
2.2 |
1.5 |
3500*1500*2200 |
6500 |
Machine Running Condition :
Supply Water Temperature : 23 Centi degree
Evaporator Tempeature : -15 Centi degree
Condensing Temperature : 40 Centi degree
Standard Supply Power : 380 V - 50 Hz - 3 P . We still can make ice machin with special power .
