Product Details
Capacity: | 6000kg / 24hrs | Place of Origin: | Guangdong, China | Brand Name: | CBFI |
Model Number: | MB60 | Ice Shape: | Ice Block | Certification: | CE |
Product Description
Specifications
1.Daily output from 1ton to 100tons.2.Good craft work and customized,long service life.
3.Adopt stainless steel SUS304
(1)Industrial ice block making machine structure: Compressor unit, ice making pool and cooling tower-water cooled system(air condenser-air cooled system).It is easy to install, just need to connect the water pipes between the three parts, and supply the power wire to the machine.
(2)Production models: we design the machine in different production models, from 1 ton per day to 100tons per day.
(3)Weight of ice:2.5kg,5kg..10kg..20kg….. also can be done as customers’ requirement.
(4)Power form supply: 380V/50HZ/3P or 230v/60hz/3p.
(5)Refrigerant: we use Freon R22 or R404a
(6)Ice model Material: we use 304 stainless steel or galvanized steel to produce ice cans for block ice machines.
Normal specification:
Ice weight bellows 25kg, we use 1.0mm 304 stainless steel;
Ice weight between 25kg~30kg, we use 1.2mm 304 stainless steel;
Ice weight above 30kg, we use 1.5mm 304 stainless steel or 2.0mm galvanized steel(upon the correct using method, the working life of galvanized steel is 5~6 years. If apply stainless steel, its price is more than 4 times of galvanized steel.)
Item No. | Production | Rated Power | Cooling Fan Power | Machine Dimension | Weight of Machine | ||
| Ton/24H | KW | KW | L*W*H | KG | ||
MB10 | 1.0 | 3.92 | 0.37 | 2820*1410*965 | 900 | ||
MB20 | 2.0 | 7.11 | 0.55 | 1700*750*1500 2220*1440*1065 | 1100 | ||
MB30 | 3.0 | 9.68 | 0.75 | 1800*750*1500 3000*1380*1065 | 1300 | ||
MB40 | 5.0 | 12.56 | 0.75 | 2000*800*1600 3110*1470*1075 | 1500 | ||
MB50 | 8.0 | 14.6 | 1.5 | 2000*800*1600 4560*1380*1150 | 1700 | ||
MB60 | 6.0 | 18.84 | 1.5 | 2000*800*1600 5340*1380*1150 | 1900 | ||
MB80 | 8.0 | 21.30 | 1.5 | 2000*1000*1800 7720*1950*1150 | 2300 | ||
MB100 | 10.0 | 26.60 | 1.5 | 2500*1200*2000 6360*3710*1565 | 2700 | ||
MB150 | 15.0 | 48.30 | 2.2 | 3100*1200*2000 9280*2260*1560 | 3700 | ||
MB200 | 20.0 | 63 | 3.75 | 3500*1500*2200 11560*4200*1565 | 4700 | ||
MB250 | 25.0 | 68.7 | 3.75 | 3500*1500*2200 12080*2260*1560 | 5700 | ||
MB300 | 30.0 | 76.4 | 5.5 | 3500*1500*2200 11560*5430*1600 | 6700 | ||
MB400 | 40.0 | 126 | 7.5 | 2*3500*1300*2200 11560*7080*1600 | 8700 | ||
MB500 | 50.0 | 137.4 | 7.5 | 2*3500*1300*2200 14170*7080*1600 | 10700 | ||
MB1000 | 100.0 | 274.8 | 15 | 4*3500*1300*2200 12000*13500*1450 | 21400 | ||
|
