Island Country Used Block Ice Machine for Fresh on Time Seafood

Name: Island Country Used Block Ice Machine for Fresh on Time Seafood
Brand: CBFI
Availability: InStock

FOB Price

US$ 1 - 100,000 / Set

1 Set(Min. Order)

Port Guangzhou
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Capacity	1ton~100tons
Place of Origin	Guangdong, China	Brand Name	CBFI
Model Number	MB10	Ice Shape	Other, Block
Voltage	380V/3phase/5Hz	Power(W)	3.92kw
Dimension(LWH)	28201410965mm	Weight	900kg
Certification	CE	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Guangzhou CBFI block ice making machine for sale

Product Description

MB Series Ice Block Making machine

MB series of ice block machine is a new type machine with high efficiency units,which mainly aiming at the Africa,Middle East and Oceania. This machinery units adopts the integrated design,easy to install,just need connect the power. The ice-making tank adpt the Polyurethane foam technology,it have good viscosity performance,avoiding the defects of foam uneven. What's more,it's designed according to the theoretic fluid,so the flow is table.

Ice block machine application: 1.ice factory of the ports, docks;

2.fresh aquatic products;

oling;

4.long distance transportation;

5.fishery;

6.food preservation;

7.special areas of cooling;

8.ice sculpture.

Block ice standard: Normaly have 5kg(Size: 150×80×500mm);10kg(Size: 100×200×600mm); 20kg(Size: 100×300/260×850mm); 25kg(Size: 120×300/260×860); 30kg(Size: 120×300/260×960mm);

CBFI 12 Tons Block Ice Machine In Philippines - CBFI /projects/cbfi-12-tons-block-ice-machine-in-philippines.html

MB Series Ice Block Maker Machine Models for Reference

Item No.	Production	Compressor Rated Power	Circulating Water Pump Power	Cooling Water Pump Power	Cooling Fan Power	Machine Dimension	Weight of Machine
	Ton/24H	KW	KW	KW	KW	LWH(MM)	KG
MB10	1.0	3.92	2.2	1.5	0.37	28201410965	900
MB20	2.0	7.11	2.2	1.5	0.55	17007501500 222014401065	1100
MB30	3.0	9.68	2.2	2.2	0.75	18007501500 300013801065	1300
MB40	4.0	12.56	4	2.2	0.75	20008001600 311014701075	1500
MB50	5.0	14.6	4	2.2	1.5	20008001600 456013801150	1700
MB60	6.0	18.84	4	2.2	1.5	20008001600 534013801150	1900
MB80	8.0	21.30	4	4	1.5	200010001800 772019501150	2300
MB100	10.0	26.60	5.5	4	1.5	250012002000 636037101565	2700
MB150	15.0	48.30	7.5	5.5	2.2	310012002000 928022601560	3700
MB200	20.0	63.0	7.5	7.5	3.75	350015002200 1156042001565	4700
MB250	25.0	68.7	7.5	7.5	3.75	350015002200 1208022601560	5700
MB300	30.0	76.4	7.5	15	5.5	350015002200 1156070801600	6700
MB400	40.0	126	15	15	7.5	2350013002200 115607080*1600	8700
MB500	50.0	137.4	15	15	7.5	2350013002000 141707080*1600	10700
MB1000	100.0	274.8	30	30	15	4350013002200 1200013500*1450	21400

Machine running condition: water temperature 23°C, evaporate temperature -12°C,condensing temperature 40°C, reference valve under 50Hz power condition. Real production of machine will have a

little change according to change of water temperature and ambient temperature.

MB Series Block Ice Maker Machine Features

1. The temperature of ice is low and it can reach 10celsius belew zero.

2. Because of the block structure,it is convenient for store.

3. The integrity design and installation convenience,it can be used if you install electricity and water.

4. The principle is simple and the maintenance and repair is easy.

5. The ice-making tank adopt the Polyurethane foam technology. It promises a good hest insulation.

6. It can be made into different size of ice block machine to meet different currents' need to ice.

7. The large ice block machine use the crane to take ice,so the work quantity is small.

8. There are 1ton to 100tons production per day models to choose.

MB Series Block Ice Maker Machine Pictures

Ice block machine 3D drawing

8ton ice block machine in our facotry

Packaging & Shipping

Our Services

Installation:

1). Installing by the user: we will tested and install well the machine before shipment, all necessary spare parts, operation manual and CD are provided to guide the installation.

2).Installing by our engineers:

(1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user provide accommodation and round-trip ticket for our engineer.

(2) Before our engineer arrived in your site, the installation place, electricity, water and installation tools should be ready. Meanwhile, we will provide you a Tool List with the machine when delivery.

(3) All spare parts are provided according to our standard. During installation period, any shortage of parts due to the actual installation site, the buyer is required to afford the cost, such as water pipes.

(4) 2~ 3 workers are required to assist the installation for big project.

Guarantee Period: During 12 months after selling, maintenance and parts free of charge
