LAPAR High-performance Double Eccentric Wafer Butterfly Valve, Pneumatic Control Butterfly Valve
- Longest Cycle Life
- Ability to meet ANSI and other critical industry standards
- Many body, trim and seat options are available to handle a variety of applications and demanding critical services
Available in multiple versions
LAPAR's HP High Performance Butterfly Valve Series offers high-performance soft or metal seated, fire-safe butterfly valves suitable for a wide range of applications. Body material is either Carbon Steel or 316SS with wafer style (HPW) or lug style (HPL) connections. PN 10-40 ANSI 150# or 300# rated.
Features & Benefits:
- Class VI Shut Off, Bubble tight
- Advanced Seat design
- Extended Neck
- Positive Seal Packing Design
- Quick Release Disc Design
- Disc Taper Pins
- Integrally cast Disc Position Stop
- Graphite Impregnated or Reinforced 316 SS Bearings
Typical Applications:
- Chemical/Petro-Chemical
- Liquified Gas / Refrigeration
- Steam
- HVAC
- Oil Refineries and Oil Field
- Power & CoGen
- Pulp & Paper Mills
- Air Dryers & Air Separators
- Sterilizers, Autoclaves and Pasteurizers
Materials:
- Seat- RPTFE
- Disc- 316SS
- Body- Carbon Steel or Stainless Steel
End Connections:
- Wafer Flange
- Lugged Flange
Driving Mode |
(5~7bar) Electric, Pneumatic |
Nominal Size |
DN65~900mm |
Pressure Rating |
150~300LB |
Working Temp. |
PTFE: -29~+150℃ |
Media |
Gas, Water, Oil |
Accessories |
Limit switch, Positioner, Solenoid valve, Air filter regulator, Handwheel |
Connection Standard |
ASME B 16.5 |
