pharmaceutical Cone Mill Machine for granules
Pharmacy:raw material grinding,wet process of granules,dry material granulation.For those tables not in requirement,they can recycled according to the size of particles.Foodstuff:for the reuse of biscuits.Others:for the grinding and granulation of coarse materials,block materials and agglomerated materials.
Raw materials entering the feeding gate will be fall into coneshaped working chamber and era sheared by rotary knifes and mesh surface.The material is cut into small particles and released from the sieve.The granule size is decided by the distance of mesh size,rotary knifes and sieve as well as the rotary knife speed.
| FZB Series Granulator | |||||
| Model | 150B | 300B | 450B | 700B | 1000B |
| Capacity(kg/h) | 15-150 | 30-300 | 45-450 | 70-700 | 100-1000 |
| Size(mesh) | 6-80 | ||||
| transfer base temperature increase(℃) | <30 | ||||
| speed control range(rpm) | Single speed:2800rpm Or frequency control of motor speed 300-3600rpm | ||||
| motor power(kw) | 1.1 | 1.5 | 2.2 | 3 | 5.5 |
| height of discharge gate from floor(mm) | 650 | 650 | 690 | 690 | 720 |
| Overall size(L×W×H) | 810×445×1345 | 850×480×1400 | 920×445×1430 | 1000×500×1530 | 1100×560×1785 |
1) Professional advice and rich experience help to choose machine.
2) Lifelong maintainance and considerate technical support
3) Technicians can be sent to abroad to install.
4) Any problem before or after delivery, you could find and talk with us anytime.
5) Video / CD of test running and installation, Maunal book, tool box sent with machine.
1 What material will you want to make granulator ?Is it dry powder or wet powder ?
2 what is your require powder size? And capacity per hour ?
3 What voltage you want? For example, 380V 50hz 3p; 440V 60Hz,3p; 220V...etc.
(We only provide 3P, because our machines are all for industrial use,not for family.)
4 Usually we use stainless steel 304,if you want stainless steel 316,it is ok.Pls feel free to tell us.
