Specifications
It is used for tensile, compression, bending, shearing, peeling, tearing, etc tests of metal and non-metal materialsUTM
Hydraulic UTM
1. Introduction
The testing machine is mainly used to process tensile test, compression test , bending test and shearing test of metallic material, it can also be used to process compression test and bending test of cement, concrete and other non-metallic material, with special auxiliary equipment it can also be used process mechanical property test of fastener, steel wire rope, components . It applies to aerospace industry, engineering inspection, university and college, mining industry, research institution and other fields. The testing machine meets to ISO, ASTM and other international test standard.
2. Main technical parameters
Parameter Model |
WEW-100B |
WEW-300B |
WEW-600B |
WEW-1000B |
Force range |
2-100kN |
6-300kN |
12-600kN |
20-1000kN |
Accuracy |
±1% |
|||
|
Round specimen diameter range |
φ6-φ22mm |
φ10-φ32mm |
φ13-φ40mm |
φ13-φ60mm |
|
Flat specimen thickness range |
0-15mm |
0-15mm |
0-30mm |
0-40mm |
|
Flat specimen width range |
40mm |
70mm |
80mm |
120mm |
Tensile space |
550mm |
620mm |
650mm |
620mm |
Compression space |
500mm |
550mm |
570mm |
580mm |
|
Upper and lower compress plates size |
φ100mm |
φ120mm |
200×200mm |
205×205mm |
Distance of bending by pass roll |
30-350mm |
100-320mm |
100-500mm |
100-500mm |
Max. piston stroke |
250mm |
250mm |
250mm |
250mm |
Power supply |
380V±10% ,50Hz |
|||
Work environment |
10-30°C, Relative humidity≤80% |
|||
|
Dimension of host machine |
730×500×2000mm |
800×500×1950mm |
950×630×2265mm |
980×650×2220mm |
|
Dimension of control cabinet |
600×600×1165mm |
|||
Weight |
1350kg |
2000kg |
2500kg |
3300kg |
