UHZ 517C11 Fuel Level Controller for High Temperature 450 Centigrade 150lb

Name: UHZ 517C11 Fuel Level Controller for High Temperature 450 Centigrade 150lb
Brand: FOXC
SKU: 114084007
Availability: InStock

Shanghai Xingshen Instrument Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

FOXC

Model Number:

UHZ 517C11

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name FOXC

Model Number UHZ 517C11

Specifications

1. good sealing, leakage proof and reliable measurement in high temperature
2. no blind area. striking in display

Technique Parameter

Measure Range:	150~8000mm (center distance) or on request.
Nominal Pressure:	PN2.5MPa Class 150LB ANSI
Working Pressure:	≤1.875Mpa 112.5LB
Working Temperature	<450°C 723.15K
Medium Density	500~2000kg/m³
Chamber(bypass tube)	Φ63.5×2.5mm
Process Connection	Factorty Standard: DN25 PN2.5MPa HG20592-97; 150LB 1" ANSI B16.5; Optional std: 1/2"~ 4" ANSI B16.5; DN10-DN50 GB/T 9112-2000; JB/T 79.1-94 SH3406-1996 DIN 2635; DN10-DN100; DIN 2527; DN10-DN100 10A~100A JIS 10K FF RF; 1/2"~4" JPI 150LB RF
Chamber/Flange/ Wetted Material	304, 316, 316L, 316Ti, 321, 1.4301, 1.4435, 1.4401, 1.4571, 1.4783, 0Cr18Ni9, 1Cr18Ni9Ti, 00Cr17Ni14Mo2, 0Cr17Ni12Mo2, 0Cr18Ni2Mo2Ti
Magnetic Float	Its size depends on liquid density Material: Titanium, 316SS or 316L SS
Optional Items	Four-magnet hi-temp level switch Three-magnet level switch Heating Jacket Depth Vacuum insulation jacket Coil type heating jacket Drain/Vent valves Remote Transmitter(4~20mA, two/ three wire,HART) Magnetostrictive level transmitter
