NDW-1000 Computerized Torsion Testing Machine
Main functions
The loading system of this machine, controlled by computer, rotates load through alternating servo motor and cycloidal gear reducer. Torque and twist angle detection uses the high-precision torque sensor and a photoelectric encoder; computer displays dynamically the curve of test torsion angle and torque, rate of loading, peak of power and so on.
Application:
This series materials torsion testing machine is used for torsion test of metal materials, nonmetallic materials, composite materials and components
Standard:
GB/T 10128-1998 “Meta torsion test methods under room temperature”
GB/T 10128-2007 “Meta torsion test methods under room temperature”
Main technical specifications
Maximum torque of test (Nm):1000
Relative error of torque:≤±1%;
Range of torsion angle measure:0~9999.9°;
Relative error of torsion angle:≤±1%;
Display of torsion angle: Minimum resolution 0.1°;
Angle of twist in small-angle measurement: Minimum of resolution 0.0001°;
Maximum distance between two collets(mm):≥500;
Diameter of clamping sample(mm):φ6~φ20mm;
Range of reverse speed:0~540°/min, Variable speed;
Precision of speed:±1%;
Direction of test rotation: Bidirectional;
Power supply: 220V±10%,50H
Technical parameter:
Model |
NDW- 100 |
NDW- 200 |
NDW- 500 |
NDW- 1000 |
NDW-2000 |
NDW- 3000 |
NDW-5000 |
|
Max Torque(N/m) |
100 |
200 |
500 |
1000 |
2000 |
3000 |
5000 |
|
Control Method |
Constant torque, constant angle, constant twist angle closed-loop control mode |
|||||||
Test class |
1 class |
|||||||
Torque test range(F·S) |
2%~100%F·S |
|||||||
Torque value relative error(%) |
≤±1 |
|||||||
Torque display resolution |
1/20000 |
|||||||
Twist angle test range(F·S) |
2%~100% |
|||||||
Twist angle value (%) |
≤±0.5 |
|||||||
Twist angle display resolution |
1/20000 |
|||||||
Twist angle value accuracy (%) |
≤±1 |
|||||||
Corner display resolution (°) |
0.01 |
|||||||
Max twist angle |
99999° |
|||||||
Twist angle rate control adjusting range(°/min) |
0.05-800 |
|||||||
Effective distance between chucks (mm) |
600 |
|||||||
Power supply |
220V±10%,50Hz |
|||||||
