Help CenterSVK 200 Digital Water Level Indicator for Vibration Level Switch
Related Products
-
BK-1 Explosion Proof Switch for Three-magnet Driven Level SwitchNegotiableMOQ: 20 Sets -
UQK10~40 Explosion Proof Switch Float Type Liquid Level SwitchNegotiableMOQ: 5 Pieces
-
UQK80 Explosion Proof Switch Connecting Rod Float Level SwitchNegotiableMOQ: 20 Sets
-
UQK10~40 Magnetic Switch Normally Open for Float Type Liquid Level SwitchNegotiableMOQ: 5 Pieces
-
UQK80 Magnetic Switch Normally Open for Connection Rod Float Level SwitchNegotiableMOQ: 20 Sets
Specifications
1. no need calibration2. user-friendly
3. endurable
4. auto-vibrate off attachment
SVK-200 vibrating rod is activated to vibrate via the piezo drive. If the vibrating rod is immersed. the amplitude will be damped. The electronic element detects this damping and converts it into a switching command. Due to the rod design, it is almost impossible for material to build up or get wedged in.
Applications:
Vibratng level switch is widely used to indicate and control material level in the field of chemical, foodstuff and petrochemical industry etc.
Powered milk wheat flour Fibrous powder
Frozen praties Casting sand Silicon powder
Legume Spice Plastic pellet
Sugar Ainimal foodstuff Pebbles
Coffee bean Saccharoid Wooden meal
Salt Peanut Tobacco
Soda Coal dust Whiting
Features
1. No calibration needed, user-friendly as well as sturdy and durable design.
2. Shed off build-up material. No fear about accumulated material on sensor.
3. High or low fail safe modes offer safety and reliability.
4. According to different density, its adjustable sensitivity wheel button can be set even for finest material.
