Specifications
1.UQK Float level switch suitable for high pressure appliactions.2. Stable and reliable in rugged condition
UQK6000 float level switches are designed as per ANSIB31.1 standard for a high temperature and high pressure applications. The advanced tri-magnet driven switch is of rational structure and good stability, it can identify the switch movement precisely even under rugged conditions. UQK6000 float level switches are applicable for level control, alarm and cascade failure of open vessel, and high temperature high pressure process conditions in the fields of petrochemical, power, food, pharmaceuticals and etc.
Features
- Unique tri-magnet mechanism, no spring, no cam and no friction surface;
- Explosion-proof sealing structure, alumina ceramics switch
- Used for high temperature, high pressure, low temperature, ultra low temperature and shock-proof applications.
- ANSI B31.1 standard design
- 316L guide rod, high temperature resistance rare earth magnet steel.
Technique parameter
Accuracy: Liquid level control±4mm
Nominal pressure: 6.3MPa, 10MPa, 16MPa, 25MPa, 32MPa, Class 300, Class600,
Class900, Class1500, Class2500
Medium temperature: max 538°C
Wetted material: 304SS, 316L, 347SS
Ambient temperature: -20~80°C
Electrical interface: NPT1/2(Female) or M20*1.5
Service life: ≥5×105
Medium density: ≥0.6 g/cm3
Safety class: Intrinsic safe: ExiaIICT4~T6;
Explosion proof: ExdIICT4~T6
Enclosure: IP67
Model Table
