Specifications
DE-508 RF capacitance level switch overcomes the two difficulties of great temperature drifts and hard calibration.UDE-508 RF capacitance switch is intelligent level switch. It utilizes RF capacitance measuring technology and digital calibration technology and overcomes the two difficulties of great temperature drifts and hard calibration. “Digital calibration technology” is especially designed for this product and brings great convenience to end-users. It will further promote the capacitance level switch to be used in much wider in various industries.
This product is easy to operation with the setting press key to set the lower and upper limit. Flexible controlling method, normally close/open contacts can be chosen freely. It has overcome the shortcomings of probe rod attachments or material splashing which may affect measurement. Under these rug service conditions, UDE-508 capacitance switch can work normally. No moving elements in the checking parts, anti-shocking, insulted PTFE applied in probe rod; high temperature and high pressure resistance, anti-corrosion, not-easy being attached.
Technical parameter
Signal output: DPDT; Relay contact output
Output capacitance: 250VAC/3A or 24VDC/5A
Power supply: 220V/110V AC±10% or 24VDC ±15%; Consumption: ≤1W
Ambient temperature:-30°C~70°C RH: ≤95%
Enclosure: IP65
Approvals: explosion-proof : ExdIIBT4, Intrinsically safe: ExiaIICT4~T6
Relative dielectric constant: ε≥1.6
Damp time: 0, 2, 4,8, 16, 32seconds
Electric interface: two groups M20*1.5 or 1/2’’ NPT
Probe length: 350mm; other length on request;
Rated temperature and pressure: 120°C/1.5Mpa; 80°C/3.0Mpa
Typical applications
- Cereals processing: for flour and wheat grain level
- Feed processing: for soybean meal level
- Thermal power industry: for coal ash level
- Building materials and glass industry: for lime and glass cullet level
- Foundry machinery industry: for cement level
- Hydraulic machine industry: for lubricating oil level
- Chemical industry: for Polyester, Polyurethane, acid and alkali level
- Water treatment industry: for sewage water level
