Home > Instruments & Meters > Meter for Liquid & Gas > Flow Meter > BBZ High Pricise Pulse Output Medical Flow Meter Turbine

BBZ High Pricise Pulse Output Medical Flow Meter Turbine

BBZ High Pricise Pulse Output Medical Flow Meter Turbine thumbnail-3

BBZ High Pricise Pulse Output Medical Flow Meter Turbine thumbnail-4

BBZ High Pricise Pulse Output Medical Flow Meter Turbine photo-1

BBZ High Pricise Pulse Output Medical Flow Meter Turbine photo-2

BBZ High Pricise Pulse Output Medical Flow Meter Turbine photo-3

BBZ High Pricise Pulse Output Medical Flow Meter Turbine photo-4

US$ 320 - 3,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Henan, China

Brand Name:

BBZ

Model Number:

BBZ

Contact Supplier Request Quote Chat Now

Henan BBZ Automation Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Lianyungang Qingdao Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Henan, China

Brand Name BBZ

Model Number BBZ

Product Description

Introduction:

BBZ High pricise pulse output medical flow meter turbine can display various units, like cubic meters, gallons, liters, standard cubic meters, the standard liter etc. BBZ- Insertion turbine flow meter can set a fixed pressure and temperature parameters to compensate for the gas. As for those occasions when pressure and temperature parameters change little , insertion turbine flow meter can be used to fix the compensation totalizer. If supporting the display instrument with a special function, It can used for quantitative control, excessive alarm and other functions as an ideal flow measurement and energy meter.

Specifications:

Range ratio	1:20 for medium and large caliber 1:10 for small caliber
Power supply	Two-wire system: +24VDC Three-wire system: +12VDC～＋24VDC
Ambient temperature	-20～50℃
Relative temperature	5%～95%
Barometric pressure	86～106Kpa
Measured medium temperature	-20℃～120℃
Explosion proof	ibⅡBT6
Display	7 LCD display cumulative flow units (m3); 7 LCD display instantaneous flow units (m3 / h)
Local display power supply	3.6V (Lithium battery, may be used continuously for more than 3 years)
Display mode	local LCD displays instant flow and cumulative flow
Accuracy	±0.5%, ±1％ ±0.2%
Repeatability	0.05%~0.2%
Signal transmission distance	Distance sensors and monitors up to1000m
Power supply	DC24V
Inductance	40mV p-p
Output signal	Pulse output

Application

BBZ High pricise pulse output medical flow meter turbine widely used in the measurement and control in petroleum, chemical, metallurgy, research and other fields. Equipped with an insertion turbine flowmeter with sanitary coupler , this flowmeter can be used in the pharmaceutical industry.
