Application and purpose
By application of theory of negative-pressure collection and positive pressure discharging.CIMC5315GXP Multifunction Combination Suction & Discharging Vehicle is for suction dry or wet material and discharging material into reclaimed warehouse or designated position. The vehicle functions as material collection, transportation and discharging, which has various advantage as resource saving, environment protection and lessen labor effort.
The vehicle not only can be applied for solid, powder or liquid material like cement, coal powder, lime powder, steel powder, etc wherever need, also for emergency case treatment, as collecting toxic material when environment pollution accident occurs.
Second,The main technical parameters
| NO. | Project Name | Detailed description | |
| 1 | Whole tank vehicle | Vehicle Name | Multi-function joint suction vehicles |
| Model | CIMC5310GXW | ||
| Chassis | Heavy Duty Truck | ||
| Wheelbase | 1800+4200+1350 | ||
| The total mass kg | 31000 | ||
| Load weight kg | 8500 | ||
| Dimensions (mm) | 10760×2496×3960 | ||
| 2 | Engine | Emission Standards | Euro III |
| Power kw | 221 | ||
| Fuel Type | Diesel fuel | ||
| 3 | Material tank | Tank volume m3 | 18 |
| Tank size (diameter × length) mm | 2100×5410 | ||
| Tank material | 16MnHigh strength steel | ||
| Tank wall thickness mm | 6 | ||
| Feed valve | 6Inch | ||
| Lift the tank | ≥50Degree | ||
| 4 | Vacuum system | Vacuum degree bar | -0.5 |
| Maximum air flow m3 / h | 5709 | ||
| Mm maximum particle material | 15 | ||
| Pumping distance m | ≥50 | ||
| 5 | Discharge System | Working pressure bar | 2 |
| The maximum displacement m3 / h | 500 | ||
| Discharge capacity t / h | 30-70 | ||
| Discharge height m | 15-30 | ||
| Discharge valve | 4Inch | ||
| The remaining rate ‰ | ≤2 | ||
