Help CenterQINGLING VC46 Mixer Truck With 8-12 M3 Mixer Tank
Related Products
-
QINGLING VC46 Mixer Truck 8X4US$ 78,000 - 88,000MOQ: 1 Unit -
QINGLING VC46 Dump Truck/Tipper Truck 8x4US$ 70,000 - 75,000MOQ: 1 Unit
-
QINGLING VC46 6X4 Lorry Truck/Van TruckUS$ 56,000 - 65,000MOQ: 1 Unit
-
QINGLING VC46 6X4 NEW Tractor Truck/Prime Mover/Tractor Head/Tow TruckUS$ 54,000 - 60,000MOQ: 1 Unit
-
QINGLING VC46 Dump Truck/Tipper TruckUS$ 65,000 - 71,000MOQ: 1 Unit
QINGLING ISUZU truck, started production in China since 2015, with stable quality in the world!
New ISUZU mixer truck model with most competitive price from China:
Model QL5250ULCZ
Driving type: 6*4 left hand driving
Engine Make: ISUZU
Diesel 4-stroke direct injection diesel engine, Electronic control
Engine model:6UZ1-TCG40 , Euro IV emission standard
6-cylinder in-line with water cooling, turbo-charging and intercooling
Maximum output: 350 hp (257 Kw) at 2000 rpm
Displacement: 9.8 L
Transmission Fuller 9JS150TB, 9 forwards and 1 reverse, 1500N.m, 2600rpm
Ratio: 12.65 8.38 6.22 4.57 3.40 2.46 1.83 1.34 1 13.22 (R)
Front Axle ISUZU F075, Steering with doubleT-cross section beam, 7.5 Tons Capacity
Rear Axle ISUZU RT210, Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles .
18 Tons Capacity, Ratio Selective:3.9, 4.1, 4.3
Wheels & Tyres Tire:11.00-20 18PR, all Nylon tyre
Driver's Cab Standard cab, with two seats, 1 bed, 2-arm windscreen wiper system with three speeds
Parameter of the Mixer Tanker Agitating Volume m³ 8
Charge speed m³/min ≥3
Discharge speed m³/min ≥2
Surplus % ≤0.5
Drum speed rpm 0~16
Drum inclination º 15º
Drive system Decelerator ZF Germany P5300
Pump EATON USA 5423-159
Hydraulic motor EATON USA 5323-138
Water supply system Water tank volume L/Form of 400/Electric water pump
