Specifications
1.real power by laser meter2.many power to choose: 5mw,10 to 20mw,30mw,50mw,100mw
3.add line or switch free,as your demand
100mw green laser module
The green laser module is a kind of industrial semi-finished products,can be apply to many areas.The light is straight,long distance and thin.For customes’convinence,we usually connect two lines outside.The black line is design to connect with the negative electrode “-”,the red line is design to connect with the anode “+”.There is a press key on the board,if you do not need to control on the board,we will short circuit it,so you can add another key outside.
Working details:
5mw 2.5V---3.0V current is limited to 150mA---280mA
30mw 2.5V---3.0V current is limited to 220Ma----320mA
50mw 2.5V---3.0V, current is limited to 200mA---350mA
100mw 2.5V---3.0V current is limited to 280mA----380mA
150mw 2.5V---3.0V current is limited to 350mA----600mA
200mw 2.5V---3.0V current is limited to 500mA----680mA
Light match module: 2.5V—3.0V current is limited to 400mA----600mA,it is design to light a match and burn black things.
Worning: do not put too high voltage on it,otherwise the module will be burn and fail working.
And do not try to adjust the adjustable resistance on the board to change the current.
Size:<55mm*9mm
