49600L LPG Semitrailer

49600L LPG Semitrailer thumbnail-1
49600L LPG Semitrailer photo-1
US$ 1 - 1,000,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hubei, China
Contact Supplier Request Quote Chat Now
Hubei Qixing Vehicle-Body Limited Company
Payment & Shipping
Payment Methods:
Port of Shipment:
Wuhan or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hubei, China

Items

Data

Items

Data

Product ID: LW1900




Gross Vehicle Weight (GVW)

   36132 Kg



Design temperature

≤50 °C

Payload

  21350Kg

Filling medium

LPG (Propane)

Water capacity

      49.6m3

Tank material

Q345R

Pressure of leak test

  1.61 Mpa

Corrosion allowance

1.0mm

External Dimensions

(length×width×height)

12740×2480×3800mm

Heat treatment method

PWHT

Semitrailer curb weight

 15300Kg

Hydraulic test

Pressure

2.74  Mpa

Full load



Fifth wheel load

14260Kg

Internal Dimensions Internal

(length×diameter)

12372×2300mm

  Rear axle load

21880Kg

Max. vehicle roll angle

>350

Design the limited velocity

Straight road

80 Km/h



Vessel's sort



The third kind

Turning

20 Km/h

Service Years

Ten years







U.

V

Japan Type

QGJ43F-2.5

Or

FISHER internal valve

C427-16-25

C427-24-50





S

.

V

Type

A412F-2.5

Or

FISHER Relief valve

H732-275

Nominal pressure

PN2.5Mpa

Model

Inner full lift

Nominal diameter

Gas phase

DN 25mm

Nominal pressure

PN2.5 MPa

Liquid phase

DN 50mm

Nominal diameter

DN80mm

Operation way

Manual

Opening pressure

1.92~2.01 MPa

Closing time

10 Sec

Closing pressure

>1.54 MPa

Melting switch temperature

70±5°C

Complete opening

Pressure

<2.19 MPa

I.

L

Type

YWJ-2.5A

RN1200



L.U.

S



Valve type

Q41F-2.5P

/CQA41F-25P

Model

Rotary type

Model

Quick tie-in

Nominal pressure

PN2.5Mpa

Nominal Diameter

Gas phase

DN25mm

Surveying range

0~2400mm

Liquid phase

DN50mm

Precision

2.5 Grade

Wheel base

6880+1310+1310mm

Tire

12.00-20

Production cycle

55-60 days

FOB PRICE

USD

CNF PRICE

USD





49600L LPG semitrailer

NO.

 NAME

1

  Little head

2

piazza light

3

Flying rings

4

  Body

5

  Safety valve

6

Manhole

7

  Big head

8

  Indicator of liquid level

9

Nameplate

10

  Rear bumper

11

  Seat

12

  Plate for protecting tyre

13

  Valve box and operation system

14

  Side protecting rail

15

  Seat of support leg

16

  Seat of king pin

 49600L LPG semitrailer49600L LPG semitrailer
