Specifications
ON Stock!!Yanan Diesel Generator Trailer1.Power by famous engine,Cummins
2.OUTPUT:134KW/167.5KVA
3.Insulation class:H.
ON Stock!!Yanan Diesel Generator Trailer
About Generator Set
| Genset Model | C134/S |
| Continuous output | 134/168 |
| standby output | 145/180 |
About Diesel Engine
| Diesel engine model | 6CTA8.3-G2 |
| CHARACTERS | AIR-cooled in line 4-stroke direct injection wet cylinder liner |
| continuous output | 175 |
| Displacement | 190 |
| compression ratio | 14:5:1 |
| Lub oil capacity | 50 |
About Alternator
| Alternator Model | SLG274E |
| Continuous output | 134/168 |
| Characters | 4pole,roting field,brushless self excited,H class insulation,IP23, |
| voltage regulation | ±1.0%with4%engine governing |
Accessories:
1)Standard accessories: Standard 40°C radiator mounted on skid. Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wire, Standard tool skit, operation manual and document.
2) Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heating exchange, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer
Warranty policy:
Guarantee for one year or 1200 hours (accord to whichever reach first)from ex-factory date.During the guarantee period,our company will provide the free easy-damaged spare part for problems caused by our quality of production or raw material,except the damageable spare parts of diesel engine caused by customer's incorrect man-made operation.After expiration,our company provides cost spare parts maintenance for gen-set.
Manfuacturing standard:
ISO8528, ISO1105,ISO3046; GB/T2820,GB755,BS5000, NAMAMG-22,YD/T502
1. Reliable Performance:
Reliable Performance is the major advantage of YANAN products, and this reliability is based on the outstanding design in every aspect and strict Q.C. System.
2. Customer First:
We devote ourselves to develop products to meet customers' requirements .Our engineer develop and design new products for customers.
3. Technical Support and Service
:our engineer team will solve your technical problems within 48 hours.
4. Strict test process before ex-factory :
Every product will be tested twice before ex-factory
5. Certification:
CE,ISO,UL,TUV,CCS
OPTIONAL FEATURES:
1. Type: Open type / Silent type
2. Alternator: China Stamford / Original Stamford/ YANAN SLG Series
3. ATS: Yes / No
4. Control Panel: Smartgen / Deepsea / ComAp/ Dadakom
5. Trailer: Yes / No
6. Lighting tower: Yes / No
7. Heater: Yes / No
8.Container :Yes / No
To meet your need is our pleasure,please feel free to contact with us if some generators meet your demond!
