Wireless 3G Repeater UMTS WCDMA 2100Mhz Mobile Phone Signal Amplifier Booster
Telecom WCDMA 2100MHz 3G Repeater Mobile Phone Signal Booster which is much cheaper than adding a new Base Station (BTS). Main operation of RF Repeaters system is to receive low-power signal from BTS via radio frequency transmission and then transmit the amplified signal to the areas where network coverage is inadequate. And the mobile signal is also amplified and transmitted to the BTS via the opposite direction.
Main Features
- High linearity PA; High system gain;
- Intelligent ALC technology;
- Full duplex and high isolation from uplink to downlink;
- Automatic Operation convenient operation;
- Integrated technique with reliable performance;
- Local and remote monitoring (optional) with automatic fault alarm &remote control;
- Weatherproof design for all-weather installation;
Technical Specifications
Items |
Testing Condition |
Specification |
||||
Uplink |
Downlink |
|||||
Working Frequency(MHz) |
Nominal Frequency |
890 – 915MHz |
935 - 960MHz |
|||
1920 – 1980MHz |
2110 – 2170MHz |
|||||
Gain(dB) |
Nominal Output Power-5dB |
85±3 |
||||
Output Power (dBm) |
GSM modulating signal |
33 |
33 |
|||
ALC (dBm) |
Input Signal add 20dB |
Po≤±1 |
||||
Noise Figure (dB) |
Working in-band(Max. Gain) |
≤5 |
||||
Ripple in-band (dB) |
Nominal Output Power -5dB |
≤3 |
||||
Frequency Tolerance (ppm) |
Nominal Output Power |
≤0.05 |
||||
Time Delay (us) |
Working in-band |
≤5 |
||||
GSM |
Peak Phase Error(°) |
Working in-band |
≤20 |
|||
RMS Phase Error (°) |
Working in-band |
≤5 |
||||
WCDMA |
EVM(%) |
Working in-band |
≤12.5 |
|||
PCDE (dB) |
Working in-band |
≤35 |
||||
Gain Adjustment Step (dB) |
Nominal Output Power -5dB |
1dB |
||||
Gain Adjustment Range(dB) |
Nominal Output Power -5dB |
≥30 |
||||
Gain Adjustable Linear(dB) |
10dB |
Nominal Output Power -5dB |
±1.0 |
|||
20dB |
Nominal Output Power -5dB |
±1.0 |
||||
30dB |
Nominal Output Power -5dB |
±1.5 |
||||
GSM |
Inter-modulation Attenuation (dBc) |
Working in-band |
≤-45 |
|||
WCDMA |
±5.0 |
Working in-band |
≤-45 |
|||
±10.0 |
Working in-band |
≤-50 |
||||
Spurious Emission(dBm) |
9kHz-1GHz |
BW:30KHz |
≤-36 |
≤-36 |
||
1GHz-12.75GHz |
BW:30KHz |
≤-30 |
≤-30 |
|||
Kingtone Repeater Packing:
Each 1pc into 1 carton,padded with safety foam;
2W Approx.: 44x24x34cm,weight approx.:10kgs;
5W approx.:61*41*29cm,weight approx.: 25kgs;
10W approx.:67*47*32cm,weight approx.: 26kgs;
20W approx.:75*52*32cm,weight approx.: 32kgs;
Kingtone Repeater Shipping:
We support: DHL, UPS, TNT, Fedex and EMS or customized
UPS,DHL,FEDEX: 3-7 WORKING DAYS TO MOST COUNTRY
EMS: 7-10 WORKING DAYS TO MOST COUNTRY
At Present, Kingtone exhibited the highest quality products and enterprise’s comprehensive strength. And Kingtone continues to strengthen technological innovation on repeater products and will launch the new products on the market soon.
With your supports and new requirements which can make us improve our service, innovative our technology and consummate the products.
OEM & ODM are welcome!
Telecom WCDMA 2100MHz 3G Repeater Mobile Phone Signal Booster to expand signal coverage of fill signal blind area where signal is weak or unavailable.
Outdoor: Airports, Tourism Regions, Golf Courses, Tunnels, Factories, Mining Districts, Villages etc.
Indoor: Hotels, Exhibition Centers, Basements, Shopping Malls, Offices, Packing Lots, hospital etc.
It is mainly applicable to such case:
The repeater can find an installation place which can receive pure BTS signal at strong enough level as the Rx Level in repeater site should be more than -70dBm;
And can meet the requirement of antenna isolation to avoid self-oscillation.
Since 2006, Kingtone has been developing and manufacturing Repeaters included CDMA Repeater, GSM Repeater,DCSRepeater, PCS Repeater, UMTS(W-CDMA) Repeater, Tetra Repeater, iDEN Repeater, Wimax Repeater and 4G LTERepeater etc.
Moreover, Kingtone Repeater have different types included Full Band-selective Repeater, Channel-selective Repeater,Frequency-shifting Repeater, Fiber-optical Repeater, Trunk-amplifier etc.
The repeaters can be Single-band Repeater, Dual-band Repeater and Tri-band Repeater etc. The Multiple Bands for different Mobile Operators.
As well as the repeater, the passive circuits such as Power Splitters, Directinal Couplers, POI, Connectors, Antennas etc. are in operation.
.
1. Q: Does OEM & ODM order available?
A: Yes, customer's Logo or design is available;
2. Q: What is the product warranty?
A: One year warranty offered for Kingtone products.
3. Q: How long can I get the products?
A: Normally 10-15 days for production, depends on order quantity.
4. Q: What is the delivery method?
A: Multiple delivery method for selection, by air, land, sea or expression courier.
5. Q: What type of system can you support?
A. Single-band repeaters of LTE/GSM/CDMA/PCS/DCS/WCDMA
B. Dual-band repeater of GSM/DCS; GSM/WCDMA; CDMA/PCS;
C. Tri-band repeater of GSM/DCS/WCDMA
D,Trunk Amplifier
E. All kind of Antenna/Splitter/Connector/Cable
|
Anna Yao
|
|
Quanzhou Kingtone Optics & Electronics Technology Co., Ltd
Add:3th Floor,Bld B,Yucheng Base, Keji Road,Fengze district ,Quanzhou ,Fujian,China.
|
|
Tell: +86 595 28857992 Fax: +86 595 22155502 Whatsapp: +86 13178207380 skype: anna.yao696 Web: |
For more details of Telecom WCDMA 2100MHz 3G Repeater Mobile Phone Signal Booster,welcome you to contact us now!
