Hangji brand rebar mill
Main parameters:
Rolling speed:max. 90m/s or 135m/s( two speed design)
Weight of a coil: 1-2.5T
Capacity:300,000-800,000TPA
Design feature
Arrangement of mills: |
Continuous rolling line Alternatively arranged H-V mills for pre-finishing mills Top 45°crossing high speed rolling mill monoblock |
Rolling speed: |
90-135 m/s |
Weight of a coil: |
1-2.5 T |
Production Capacity: |
350,000-800,000TPA |
Specifications:
Place of Origin : |
Xian, Shaanxi province, China (Mainland) |
Brand Name : |
Hangji |
Model Number : |
hangji90/hangji135 |
Type : |
Hot Rolling Mill |
Rolling speed : |
Max 135m/s |
Place of Origin : |
China |
weight of coil : |
1-2.5T |
Type : |
Rolling Mill |
Processing Type : |
Other |
Packaging Details : |
Duly packed in ship-worthy packages / containers. |
Delivery Time : |
based on discussion between buyer and us |
Supply Ability : |
20 Set/Sets per Year based on client's requirement |
5. Delivery and payment
FOB price: |
FOB USD 3000~1000000 / Set |
Min order: |
1 Set/Sets based on client's requirement |
Loading port: |
Tianjin port or according to negoiation |
payment methods: |
L/C,T/T, Escrow |
Technical project brief introduction
-- Production line with annual capacity: According to your demand,100,000.00MT at least, automatic continuous rolling mill applied.
-- Billet size: 150*150*12000mm
-- Product specifications: Ø8-Ø32mm, 12000mm length rebar
-- Roughing rolling mill stands: Ø550 x6 short stressed rolling mill in Horizontal/vertical arrangement. 6 stands.
-- Intermediate rolling mill stands: Ø420 x6 short stressed rolling mill in Horizontal/vertical arrangement. 6 stands.
-- Finishing rolling mill stands: Ø320 x6 short stressed rolling mill in Horizontal/vertical arrangement. 6 stands. 3 of the rolling mill stands are horizontal/vertical interchangeable rolling mill stands.
-- Rolling speed: 12-18meters/second
1. Product
Material: carbon steel, structure steel, low alloy steel
Product specification: bar/rebar/wire rod Ø 6 to Ø 32 mm
2. Raw material
The production line is supposed to use continuous casting billet with size of 150*150*12000mm The allowable tolerance for section dimension of billet should be in accordance with the regulation of YB-2011-83.
3. Process layout
Roughing mill stands Ø550 X 6 (H/V) No.1 to No.6 mill stands -- Intermediate mill stands Ø420 X 6 (H/V) No.7 to No. 12 mill stands -- Finishing mill stands Ø320 X 6 (H/V) No.13 to No.18 mill stands, all mill stands driven by DC motor and continuous rolling method applied. Rolling mill No.14, 16 and 18 are Ø320 H/V interchangeable rolling mill stands
4. Process flow
Company brief introduction
Our services for you :
ü We customize the products according to customers’ requirements.
ü If you are not sure about the exact product you want,
we can give you some advices, according to your factory’s area, annual capacity, raw material, your finished products.
ü We provide the methods of the maintenance of products.
ü Engineers are available to service machinery overseas.
Please contact us freely, if here anything we can do for you.
Looking forward to hearing from you.
...
