Cold Stamping Machine (12-40mm)
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
OCEPO
Model Number:
HLY--32
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality Pressed Coupler Machine (12-40mm)NegotiableMOQ: 1 Set -
High Quality Cold Forged Machine (Dia.12-40mm)NegotiableMOQ: 1 Set
-
Cold Forged Machine (Dia.12-40mm)NegotiableMOQ: 1 Set
-
Cold Stamping Machine (Dia.12-40mm)NegotiableMOQ: 1 Set
-
Cold Forged Machine (12-40mm)NegotiableMOQ: 1 Set
Place of Origin
Beijing, China
Brand Name
OCEPO
Model Number
HLY--32
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Cold Forged Machine:1. Connect rebars with dia from 16mm-32mm
2. High quality at favorable price
3. Easy to operate
Cold Stamping Machine (12-40mm) :
HLY--32 Cold Forged Machines are mainly used to connect HRB335 and HRB400 Ribbed Rebar with diameter 18-40mm, and suitable for high-rise, frameset, tunnel, bridge and dam etc. Our cold forged machines and related equipments are small in bulk, light in weight and particularly fit for construction site. Trough the strict detection of the National Metallurgy Department Construction Quality Supervision & Inspection Center, the joint reaches the Level A of National Industry StandardGeneral technical specification for mechanical splicing of bars . The practice shows that our machines are stable in quality and high in economic benefit.
Parameter:
| Rated Working Pressure | 70 Mpa | Rated Extrusion Force | 550 KN | |
| Transmission Mode | Motor Transmission | |||
| Working Medium | 10# Hydraulic Oil (Use in Winter), 20# Hydraulic Oil (Use in Summer) | |||
| Pump | Slipper Pump (Flow Rate: 3L/min) | |||
| Piston Stroke | 40 mm | Extrusion Force | 630KN | |
| Speed | Working Speed | 3.5mm/s | ||
| Return Trip | 9mm/s | |||
| Motor | Y90L-4 3.0KW 380V | |||
| Oil Tank Capability | 20 L | |||
| Dimension | 555*470*700 mm | |||
| Net Weight | 60kg | |||
