MT318-625
RFID/Contactless Card Readers for Fuel/CNG/LNG Dispensers
These are custom design contactless card readers by MINGTE card related technologies, which excel in various fields, including Kiosk Terminals, Vehicle Charging Piles, Pay Systems, POS terminals and other ID Terminals etc.
High reliability and durability
Support contactless IC card (ISO14443 TYPE A & B)
Support S50 & S70 (Mifare) card (ISO14443 TYPE A & B)
Support PSAM & ESAM card (ISO7816), optional PSAM and ESAM
Supplied with 2 card slots (PSAM or ESAM)
Customized for financial applications, easy and cost-effective for secondary development
Various correspondingand custom design
Software updated via RS232 supported
Carefully-designed antenna size for most installation design
Various installation dimensions design, temperature-proof
CARD TYPE |
Contactless IC Cards SIM Cards, PSAM Cards, ESAM Cards |
|
CONTACTLESS CARD |
ISO14443 Type A & B & Mifare |
R/W |
IC CARD |
SIM/PSAM/ESAM |
R/W |
EMV |
Level 1 Compliant |
|
CARD READING DISTANCE |
4-8cm and 106Kbit (Related to cards and installation environment) |
|
INTERFACE |
RS-232/TTL(uart) |
|
BAUD RATE |
9600/38400/57600/115200bps |
|
ANTENNA |
PCB Antenna |
|
FREQUENCY |
13.56MHz |
|
COMMUNICATION SPEED |
106Kbit(212Kbit & 424Kbit pps commands optional) |
|
SECONDYARY DEVELOPMENT |
VC, Linux |
|
OPERATING SYSTEM |
Windows 98, Me, 2K, XP, 2003, Vista and Linux |
|
DATA STORAGE CAPACITY |
Standard capacity inside reader: 4k bytes |
|
STATUS DISPLAY |
LED indication light for power & communication status, user controlled buzzer |
|
POWER SUPPLY |
DC5V or +8-15V ± 5% |
|
CURRENT |
Static Current: ≤25mA(5V) Current: ≤130mA(5V) |
|
WORKING TEMPERATURE |
-40-+65°C |
|
WEIGHT |
Approx 32g |
|
ATMs, CDMs, Kiosk Terminals, Payment Systems, Vending Machines, Gaming Machines, Parking Systems
Fuel Dispensers, CNG Dispensers, Electric Vehicle Charging Points/Piles & Stations
POS Terminals, ID Terminals, Security and Access Control Terminals, Credit Authorization Terminals
Founded in January 2005, SHENZHEN MINGTE TECH CO., LTD. (MINGTE) is a global leader in core components for Self-service Terminals. Specializing in design, development, sales and manufacturing of Smart Card Readers, Bill Acceptors and Card Collectors & Dispensers, MINGTE provides OEM and complete custom payment solutions for every imaginable application, including ATMs, CDMs, Kiosk Terminals, Payment Systems, Vending Machines, Gaming Machines, Parking Systems, Fuel Dispensers, CNG Dispensers, Electric Vehicle Charging Points and other Terminals.
MINGTE offers a full line of Smart Card Readers, Bill Acceptors and Card Collectors & Dispensers with a variety of manual dip, manual swipe, motorized, standalone, contactless, mobile payment types and single feed bill acceptors. MINGTE has a creative talent pool in both engineering and management. In its engineering team, more than 85% employees have almost 10 years’ experience in the field of smart card payment.
MINGTE has obtained various patents relating to smart card reader technologies, and passed various quality inspection tests from China Bank Card Test Center, EMV Consortium, and China Ministry of Information Industry.
