HASL FR4 consum electron segway OEM pcba manufacture
Welcome to Hangzhou Frankever Electronic Co., Ltd.
We are a leading OEM PCBA producer from Hangzhou,China!
Frantronix is specialized in manufacturing all kinds of PCBA for home appliance and communication industry.Service on both OEM and ODM project. We have been in this line for more than 10 years.With the professional R&D team and skillful workers, we can put your design into physical product, and also put your idea into workable design and product. We can offer you one stop solution from PCB, Components purchasing, Components assembly,test to the whole fabrication.
| ITEM | Parameter |
| Layer count | 1-16 layers |
| Material | fr4,Tg=135,150,170,180,210,cem-3,cem-1,al base,teflon,rogers,nelco |
| Copper thickness | 1/2oz,1oz,2oz,3oz,4oz,5oz |
| Board thickness | 8-236mil(0.2-6.0mm) |
| Max. panel size | 32"X20"(800X508mm) |
| Min.line width/space | 3/3 mil(75/75um) |
| Min. innerlayer annular ring | 4 mil(0.10mm) |
| Min. core thickness | 4 mil(0.10mm) |
| Surface treating of innerlayer | brown oxide |
| Innerlayer ragistration | 3 mil(76um) |
| Tolerance of board thickness | +/- 12-10 % |
| Min. drill size | 8 mil(0.2mm) |
| Min. HDI laser drill size | 3 mil(0.067mm) |
| Tolerance of hole size | 2 mil(0.05mm) |
| Tolerance of hole position | 2 mil(0.05mm) |
| Max. aspect ratio | 10:01 |
| PTH copper thickness | 1 mil(25 um) |
| Solder mask color | Green,blue,yellow,white,black,red |
| Solder mask thickness | 5-30um |
| Solder mask hardness | 6H |
| Min. solder mask dam | 3 mil(75um) |
| Max. hole size of S/M plug | 24um(0.6mm) |
| Peelable solder mask | yes |
| carbon ink | yes |
| surface treating | HASL(ROHS), ENING,OSP,IMMERSION SILVER,IMMERSION TIN,flash gold,gold finger |
| Nickel thickness | 120-240u"(3-6um) |
| Gold thickness | 2-30u" (0.05-0.76um) |
| Impedance control | Ohms+/-10% |
| Blind hole/buried hole | yes |
| Half hole | yes |
| Sink hole | yes |
| HDI | 1+1+N+1+1 |
| VOP | yes |
| Rouuting tolerance | +/- 6um(0.15mm) |
| V-cut | yes |
| Solderability test | 245' C, 5S |
| Thermal stress test | 280 ℃/10 secs |
| Feel strength of line | ≥61B/In(≥ 107g/mm) |
Why choose us?
- We can do PCB Fabrication, Component Assembly, Wire Harness Assembly, Box Assembly, Component Forming and Electrical Testing.
- We are certified with: ISO9001 and ROSH if required.
- We purchase material from Original Company and distributers.
- We make products by strict engineer processes.
- We have strict inspection processes.
- We send products by antistatic package and carton box.
Quote Requirements for PCB and PCBA
- PCB Gerber File and Bom List;
- Quantity;
- Technical requirements for quoting reference;
- Clear pictures of PCB or PCB Assembly sample if available.
- Testing program for PCB Assembly
Payment terms
- Payment by Paypal, Wester union,T/T or others all are ok for us.
